Chapter 4 Configuration Tables and Fields
Voice Table
BC T1/T1 E/H Back card type (CDP Set). Use
workstation Help or F12 key
for choice list.
BC1 /
BC2
*/*
Until Release 9.1, field
was determined
heuristically, based on
the observed ports
used.
Fdr1ID 0 E Feeder 1 ID. Logical port
number for the connection at a
3810 or FastPAD feeder at the
local site (not used).
FDR_ID *
MC 3810 feeders are
not supported.
Fdr2ID 0 E Feeder 2 ID. Logical port
number for the connection at a
3810 or FastPAD feeder at the
remote site (not used).
FDR_ID2 *
MC 3810 feeders are
not supported.
FdrBc / O/H Feeder back card voice card
type.
FDR_INT1 /
FDR_INT2
*/*
Index 0 O SNMP Connection Index for
CWM reference for this
connection.
SNMP_INDEX *
Rt_Metrics AW M How the connection is routed.
RT_MET
Cost 0 O Maximum cost allowed for the
least cost routing path for this
connection.
MAX_COST
DR N O Direct routing. Indicates that
the connection must use the
preferred route provided. If it
cannot use the preferred route,
the connection should not be
routed.
DR
Preferred_
Route
O The preferred route of the
connection. The first and last
routing site are optional and all
feeder sites are optional. An
equal sign separates the site
names. Specific links are
specified by the slot.port for the
incoming and/or outgoing port.
Route is stored in
19 fields:
PR_SITE2,
PR_SITE3,
PR_SITE4,
...
PR_SITE20
*
Available starting with
Release 7.2. Specific
Trunk not available
until Release 8.4.
Routes are not
available on PNNI
networks.
*
Table 4-6 Voice Table (continued)
