Chapter 4 Configuration Tables and Fields
Data Table
%Util. 60/60 E Connection utilization percentage for
DFM connections; not used if DFM
column is N.
PCT_UTIL1 /
PCT_UTIL2
Defaults used prior to
Release 8.5 and for
FastPAD. The data may
be unreliable if it
changed after adding a
connection.
*
BC V/V E/H Back card type (L4, L8, D, R, V, S, E1,
T1 and J1). Use workstation Help or F12
key for choice list.
BC1 /
BC2
*/*
Heuristic, based on
observed number of
ports used until Release
9.1.
Fdr1ID 0 E Feeder 1 ID. Logical port number for the
connection at a 3810 or FastPAD feeder
at the local site (not used).
FDR_ID1 *
MC3810 feeders not
supported.
Fdr2ID 0 E Feeder 2 ID. Logical port number for the
connection at a 3810 or FastPAD feeder
at the remote site (not used).
FDR_ID2 *
MC3810 feeders not
supported.
FdrBc / E/H Feeder back card. The line interface type
at the feeder.
FDR_INT1
Index 0 O SNMP Connection Index for CWM
reference for this connection.
SNMP_INDEX *
Rt_Metr
ics
AW M How the connection is routed.
RT_MET
Cost 0 O Maximum cost allowed for the Autoroute
least cost routing path for this
connection.
FDR_INT2
DR N O Direct routing. Indicates that the
connection must use the preferred route
provided. If it cannot use the preferred
route, the connection should not be
routed.
DR
Preferre
d_Route
O The preferred route of the connection.
The first and last routing site are optional
and all feeder sites are optional. An equal
sign separates the site names. Specific
links are specified by the slot.port for the
incoming and/or outgoing port.
Route is stored in
19 fields:
PR_SITE2,
PR_SITE3,
PR_SITE4,
...
PR_SITE20
*
Available starting with
Release 7.2. Specific
Trunk not available until
Release 8.4. Routes are
not available on PNNI
networks.
*
Table 4-7 Data Table (continued)
Field
Defaul
ts
Note
s Description and Comments DBF CET TPI
