Chapter 4 Configuration Tables and Fields
Bursty Table
FS Y O Y/N flag indicating if the connection has
ForeSight implemented or not. Foresight
only applies to FR and ABR connections,
or FR ATM multi segment connections.
FS
MIR(SCR/
MCR)
64.0/64.0 M Minimum Information Rate that is
guaranteed (in kbps for FR or ATF), or
Minimum Cell Rate for VBR/ABR
(Ignored for CBR/UBR).
MIR1 /
MIR2
*/*
PIR(PCR) 256.0/25
6.0
M Peak Information Rate (burst rate) that is
allowed (in Kbps for FR or ATF, or in cps
for ATM).
PIR1 /
PIR2
*/* */*
MBS 1000/100
0
0 Maximum Burst Size for ATM VBR
connections. The maximum number of cells
that are allowed to burst over a period of
time at a rate higher than the SCR.
MBS1 /
MBS1
%Util. 100/100 E Statistical estimate of the percentage of
time that a frame relay connection may
actually be transmitting at the minimum
information rate.
PCT_UTIL1 /
PCT_UTIL2
*/*
Defaults used
for FastPAD.
The data may
be unreliable
if it changed
after adding a
connection.
*/*
BC V/V M/H Back card. Type of back card. See Help or
F12 key for choice list.
BC1 /
BC2
*/*
SL back cards
are shown as
SM; number
of lines on
FRM back
card is
determined
heuristically
based on ports
used and port
speeds. Until
Release 9.1,
heuristic was
based on ports
used,
connection
type, and port
speeds.
Table 4-8 Bursty Table (continued)
Field Defaults Notes Description and Comments DBF CET TPI
