Chapter 4 Configuration Tables and Fields
Bursty Table
FrontCard O Front card. In some cases, multiple front
cards can support a service on a platform.
In those cases, you can specify the front
card you want.
FC1 /
FC2
Only filled in
for FRSM-HS
cards.
Application blank O Only required for VISM connections.
Describes if the connection is a Bearer or a
Signalling connection
APP
Values are blank,
B (Bearer) or S
(signalling)
Fdr1ID 0 E Feeder 1 hub ID. The slot port address on
the MGX 8220, 3810, or FastPAD at Site 2,
if any. Slot represents both the slot and line.
Enter 0 for NMT to assign.
FDR_ID1 *
FastPAD and
MC 3810
feeders not
supported
Fdr2ID 0 E Feeder 2 hub ID. The slot port address on
the MGX 8220, 3810, or FastPAD at Site 2,
if any.
FDR_ID2 *
FastPAD and
MC 3810
feeders not
supported
FdrBC / E/H Feeder back card—the line interface type at
the feeder.
FDR_INT1 /
FDR_INT2
Only MGX
8220 feeders
supported
FdrFC / E/H Feeder frontcard—the line interface type at
the feeder. In some cases, multiple front
cards can support a service on a platform.
In those cases, you can specify the front
card you want.
FDRFC1 /
FDRFC2
Red N P Enter Y for frame relay cards that are to be
redundant.
RED
Pr 0 O Rerouting priority—0 to 15, with 0 the
highest rerouting priority.
COS
Defaults used
until Release
8.1 (8.2 for
AT M )
Ad – O/H Restriction type. Link media types that this
connection should avoid.
AV D
Defaults used
until Release
8.1 (8.2 for
AT M ) .
CBRT N O Cell based routing flag. If set to ‘Y’, the
connection can be routed only on the cell
base routing cards. The traffic will never be
permitted to be converted into packets.
CB
Table 4-8 Bursty Table (continued)
Field Defaults Notes Description and Comments DBF CET TPI
