Chapter 4 Configuration Tables and Fields
Bursty Table
Endpoint
Address
The ID of the connection. DLCI for FR,
VPC/VCI for ATM. These addresses are the
IDs of the connection as it enters and exits
the ATM WAN cloud.
ADDRESS1 /
ADDRESS2
**
Routing
Address
The ID of the connection’s primary routing
segment.
RT_ADDRESS1/
RT_ADDRESS2
Index 0 O SNMP connection index for StrataView+
data base. This is the numeric identifier
required for the administration of a
connection created by the Connection
Manager in CWM.
SNMP_INDX
Rt_Metrics AutoRou
te
M How the connection is routed. Use
AutoRoute for AutoRoute. The type of
autoroute used will be determined by the
AR field in the site table for end one. Use
AW, CTD or CDV for PNNI routing. AW
routes strictly based on administrative
weights, CTD considers delays, and CDV
considers delay variance.
RT_MET
A - Autoroute,
W - PNNI Least
Cost,
D - PNNI Delay,
E - PNNI Delay
with variance
AW assumed
for MGX
8850, Release
2.
Cost 100 O Maximum cost allowed for the Autoroute
least cost routing path for this connection.
MAX_COST
DR N O Direct routing. Indicates that the connection
must use the preferred route provided. If it
cannot use the preferred route, the
connection should not be routed.
DR
Preferred_
Route
O The preferred route of the connection. The
first and last routing site are optional and all
feeder sites are optional. An equal sign
separates the site names. Specific links are
specified by the slot.port for the incoming
and/or outgoing port.
Route is stored in
19 fields...
PR_SITE2,
PR_SITE3,
PR_SITE4,
...
PR_SITE20
Not available
until Release
7.2. Specific
Trunk not
available until
Release 8.1.
Current route
not available
for SV+
release 8.1 or
8.2. Routes are
not available
on PNNI
networks.
Table 4-8 Bursty Table (continued)
Field Defaults Notes Description and Comments DBF CET TPI
