4-23
Cisco WAN Modeling Tools Guide
OL-10426-01, Rev. A0
Chapter 4 Configuration Tables and Fields
Bursty Table
Bursty Table Special Cases
The Bursty Traffic Table configuration information will be different for the following special cases:
• ATM Connections
• Two Segment Connections
The configuration for these types of connections are described in the sections that follow.
ATM Connections
Use the NMT to model ATM connections in the Bursty Traffic Table. Refer to Table 8-1 for information
on modeling ATM connections.
Table 4-9 ATM Connection Configuration
Topic Required Settings Comments
Modeling
ATM
Connections
Bursty Traffic table
Site 1, Site 2 fields: Enter the
connection end-point sites.
The ATM sites must be in the Site table and must support ATM
traffic types (such as an MGX 8850, a BPX, an MGX 8230 or MGX
8250, or an IGX switch with 8.2.5 functionality).
Quantity: Enter the number of
connections.
Type field: Enter ABR, CBR,
VBR, or UBR.
MCR Fields: Enter minimum
cell rate (or Committed
Information Rate or
Sustainable Cell Rate for
UBR).
All traffic values (MCR, PCR, QIR, CIR) are given in cells per
second for ATM traffic.
PCR Fields: Enter peak cell
rate.
