6-2
Cisco WAN Modeling Tools Guide
OL-10426-01, Rev. A0
Chapter 6 NMT Reports
Link Load Report
The Link Load report displays the load resources on each link in the network, based on the static load
model.
In the example below, den-sea is a cell based link where the bandwidth is 92% utilized. This link contains
80000 cells for CBR ATM traffic, 7515 cells of frame relay, and has a statistical reserve of 600, which
is not included in the total. There are 55 PVCs on the first link.
The second link, nyd-pit, uses only 6% of the bandwidth, but has reached the maximum number of PVC's
allowed on the link. Note that this is a packet based trunk, as the units are pps.
The third link, (lax-pit) is a T3 cell based trunk on a BTM card. The units displayed are packets because
the constraint on this link is the number of packets that can be received by the IGX bus.
The fourth link, (lax-nyd) is also a cell based trunk. For this link, both the packet load and the cell load
are listed because in this case the cell load is the constraint. This is because the combine time outs are
set low so most voice and data cells contain only one packet. If the link is partitioned for both AutoRoute
and PNNI, the usage of each is displayed.
Note The link load report has a DBF output format.
------------------------------- Link Load ----------------------------------
Trunk Span Load Used Maximum Load Max
Site1 Site2 Type load load units %Ld
------------- ------------- ----- -> / <- -> / <- -> / <- ---
den sea Total 87515/ 87515 96000/ 96000 cps/cps 92
(1.1) (1.1) CBR 80000/ 80000
BData 7515/ 7515
RES 600/ 600
PVC 55/ 55 1771/ 1771 pvc/pvc
nyd pit Total 426/ 426 8000/ 8000 pps/pps 6
(3.1) (3.1) Voice 426/ 426
RES 600/ 600
PVC 213/ 213 213/ 213 pvc/pvc
lax pit Total 2904/ 6824 80000/ 80000 pps/pps 9
(5.1) (4.1) NTS 630/ 630
Voice 994/ 994
BData 1280/ 5200
RES 600/ 600
PVC 237/ 237 1771/ 1771 pvc/pvc
lax nyd Total 2824/ 2824 10666/ 10666 pps/pps
(3.1) (4.1) NTS 630/ 630
Voice 994/ 994
BData 1200/ 1200
RES 600/ 600
Total 2164/ 2164 4830/ 4830 cps/cps 51
NTS 630/ 630
Voice 994/ 994
BData 540/ 540
RES 600/ 600
PVC 227/ 227 1771/ 1771 pvc/pvc
