2-9
Cisco ASR 901 10G Series Aggregation Services Router Hardware Installation Guide
OL-28105-02
Chapter 2 Preparing to Install the Router
Console Port Considerations
As a console port, hardware flow control is not supported. For instructions on installing a console
terminal, see the “Connecting the Console Port” section on page 3-20.
For cable and port pinouts, see the online document Cisco Modular Access Router Cable Specifications.
This document is provided on the documentation DVD that accompanied your router (if ordered).
