4-25
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 8.5
OL-23092-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Device Configuration Menu
“more” Softkey Timer Indicates the number of seconds that additional
softkeys are displayed after the user presses
more. If this timer expires before the user
presses another softkey, the display reverts to the
initial softkeys.
Range: 5 to 30; 0 represents an infinite timer.
Default: 5
From Cisco Unified Communications Manager
Administration, choose Device > Phone > Phone
Configuration.
Wideband Headset UI
Control
Indicates whether the user can configure the
Wideband Headset option in the phone user
interface.
Val u e s:
• Enabled—The user can configure the
Wideband Headset option in the Audio
Preferences menu on the phone (choose
> User Preferences > Audio
Preferences> Wideband Headset).
• Disabled—The value of the Wideband
Headset option in Cisco Unified
Communications Manager Administration
gets used (see Media Configuration Menu,
page 4-26
Default: Enabled
Use Cisco Unified Communications Manager
Administration > Device > Phone > Phone
Configuration.
Wideband Handset UI
Control
Indicates whether the user can configure the
Wideband Handset option in the phone user
interface.
Val u e s:
• Enabled—The user can configure the
Wideband Handset option in the Audio
Preferences menu on the phone (choose
> User Preferences > Audio
Preferences> Wideband Handset).
• Disabled—The value of the Wideband
Handset option in Cisco Unified
Communications Manager Administration
gets used (see Media Configuration Menu,
page 4-26).
Default: Enabled
From Cisco Unified Communications Manager
Administration, choose Device > Phone >
Phone Configuration.
Personalization Indicates whether the phone has been enabled
for configuring custom ring tones and wallpaper
images.
Default: Enabled
From Cisco Unified Communications Manager
Administration, choose Device > Phone >
Phone Configuration.
Table 4-14 UI Configuration Menu Options (continued)
Option Description To Change
