Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Device Configuration Menu
Recording Tone
Duration
Indicates the length of time in milliseconds that
the beep tone plays.
If the value you configure here is less than one
third the interval, then this value overrides the
default provided by the Network Locale.
Range: 0 to 3000
Note For some Network Locales that use a
complex cadence, this setting applies
only to the first beep tone.
See also: Recording Tone
From Cisco Unified Communications Manager
Administration, choose Device > Phone >
Phone Configuration.
Wideband Headset Indicates whether wideband is enabled or
disabled for the headset.
Default: Disabled
• If Wideband Headset UI Control is enabled,
you or the user can use the phone and
choose >
User Preferences > Audio Preferences >
Wideband Headset.
• If Wideband Headset UI Control is disabled,
from Cisco Unified Communications
Manager Administration choose Device >
Phone > Phone Configuration to set this
value.
Note If you allowed this option to be user
controllable (in the Wideband Headset
UI Control option), the user-configured
value takes precedence.
Wideband Handset Indicates whether wideband is enabled or
disabled for the handset.
Default: “Use Phone Default” on Cisco Unified
Communications Manager Administration.
(This default means that the phone will be
enabled for a wideband handset only if the
phone was shipped with a wideband handset.)
• If Wideband Handset UI Control is enabled,
you or the user can choose >
User Preferences >
Audio Preferences > Wideband Handset.
• If Wideband Handset UI Control is
disabled, use Cisco Unified
Communications Manager Administration
and choose Device > Phone > Phone
Configuration to set this value.
Note If you allowed this option to be user
controllable (in the Wideband Handset
UI Control option), the user-configured
value takes precedence.
Table 4-15 Media Configuration Menu Options (continued)
Option Description To Change
