Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Device Configuration Menu
Table 4-18 describes the options on the Security Configuration menu.
QoS Configuration Menu
The QoS Configuration menu displays information that relates to quality of service (QoS) for the phone.
Table 4-19 describes the options on this menu.
Table 4-18 Security Configuration Menu Options
Option Description To Change
PC Port Disabled Indicates whether the access port on the phone is
enabled or disabled.
Note If disabled, video will not work on this
phone, even if video is enabled.
From Cisco Unified Communications Manager
Administration, choose Device > Phone >
Phone Configuration.
GARP Enabled Indicates if the phone accepts MAC addresses
from Gratuitous ARP responses.
From Cisco Unified Communications Manager
Administration, choose Device > Phone >
Phone Configuration.
Voice VLAN Enabled Indicates whether the phone allows a device
attached to the access port to access the Voice
VLAN. Setting this option to No (disabled)
prevents the attached PC from sending and
receiving data on the Voice VLAN. This setting
also prevents the PC from receiving data sent
and received by the phone. Set this setting to Yes
(enabled) if an application that requires
monitoring of the phone’s traffic is running on
the PC. These applications include monitoring
and recording applications and network
monitoring software.
From Cisco Unified Communications Manager
Administration, choose Device > Phone >
Phone Configuration.
Web Access Enabled Indicates whether web access is enabled (Yes) or
disabled (No) for the phone.
For more information, see Disabling and
Enabling Web Page Access, page 8-3
Security Mode Displays the security mode that is set for the
phone.
Use Cisco Unified Communications Manager
Administration to modify.
Logging Display For use by the Cisco Technical Assistance Center (TAC), if necessary.
Table 4-19 QoS Configuration Menu Options
Option Description To Change
DSCP For Call Control Differentiated Services Code Point (DSCP) IP
classification for call control signaling.
From Cisco Unified Communications Manager
Administration, choose System > Enterprise
Parameters.
DSCP For Configuration DSCP IP classification for any phone
configuration transfer.
From Cisco Unified Communications Manager
Administration, choose System > Enterprise
Parameters.
DSCP For Services DSCP IP classification for phone-based
services.
From Cisco Unified Communications Manager
Administration, choose System > Enterprise
Parameters.
