5-30
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 8.5
OL-23092-01
Chapter 5 Configuring Features, Templates, Services, and Users
Managing the User Options Web Pages
Step 3 In the list of records that display, click the link for the user.
Step 4 Click Device Association.
The User Device Association window displays.
Step 5 Enter the appropriate search criterias and click Find.
Step 6 Choose the device that you want to associate with the end user by checking the box to the left of the
device.
Step 7 Click Save Selected/Changes to associate the device with the end user.
Make sure to provide end users with the following information about the User Options web pages:
• The URL required to access the application. This URL is:
http://<server_name:portnumber>/ccmuser/, where server_name is the host on which the web
server is installed.
• A user ID and default password are needed to access the application.
These settings correspond to the values you entered when you added the user to Cisco Unified
Communications Manager (see Adding Users to Cisco Unified Communications Manager,
page 5-28).
For additional information, refer to:
• Cisco Unified Communications Manager Administration Guide, User Group Configuration chapter.
• Cisco Unified Communications Manager Administration Guide, End User Configuration section.
• Cisco Unified Communications Manager System Guide, Roles and User Groups chapter.
Specifying Options that Appear on the User Options Web Pages
Most options that are on the User Options web pages appear by default. However, the following options
must be set by the system administrator by using Enterprise Parameters Configuration settings in Cisco
Unified Communications Manager Administration:
• Show Ring Settings
• Show Line Text Label Settings
• Show Call Forwarding
Note The settings apply to all User Options web pages at your site.
To specify the options that appear on the User Options web pages, follow these steps:
Procedure
Step 1 From Cisco Unified Communications Manager Administration, choose System > Enterprise
Parameters.
The Enterprise Parameters Configuration window displays.
Step 2 In the CCMUser Parameters area, specify whether a parameter appears on the User Options web pages
by choosing one of these values from the Parameter Value drop-down list box for the parameter:
