Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
Model Information Screen
Model Information Screen
The Model Information screen includes the options that are described in Table 7-1.
To display the Model Information screen, press the Settings button and then select Model Information.
To exit the Model Information screen, press the Exit softkey.
Table 7-1 Model Information Settings
Option Description To Change
Model Number Model number of the phone. Display only—Cannot configure.
MAC Address MAC address of the phone. Display only—Cannot configure.
Load File Identifier of the factory-installed load running
on the phone.
Display only—Cannot configure.
Boot Load ID Identifier of the factory-installed load running
on the phone.
Display only—Cannot configure.
Serial Number Serial number of the phone. Display only—Cannot configure.
MIC Indicates whether a manufacturing installed
certificate (used for the security features) is
installed on the phone (Yes) or is not installed on
the phone (No).
For information about how to manage the MIC
for your phone, refer to the Using the Certificate
Authority Proxy Function in Cisco
Unified Communications Manager Security
Guide.
LSC Indicates whether a locally significant certificate
(used for the security features) is installed on the
phone (Yes) or is not installed on the phone
(No).
For information about how to manage the LSC
for your phone, refer to the Using the Certificate
Authority Proxy Function in Cisco
Unified Communications Manager Security
Guide.
Call Control Protocol Indicates whether the phone is running under
SCCP or SIP.
See Using Cisco Unified IP Phones with
Different Protocols, page 2-14.
