Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
Status Menu
Network Statistics Screen
The Network Statistics screen displays information about the phone and network performance. Table 7-3
describes the information that displays in this screen.
To display the Network Statistics screen, follow these steps:
Procedure
Step 1 Press the Settings button.
Step 2 Select Status.
Step 3 Select Network Statistics.
To reset the Rx Frames, Tx Frames, and Rx Broadcasts statistics to 0, press the Clear softkey.
To exit the Network Statistics screen, press the Exit softkey.
Trust List updated The CTL file, the ITL file, or both files are
updated.
None. This message is informational only.
For more information about the Trust List, refer
to Cisco Unified Communications Manager
Security Guide.
Version error The name of the phone load file is incorrect. Make sure that the phone load file has the
correct name.
XmlDefault
corresponding to the
phone device name
Name of the configuration file. None. This is an informational message
indicating the name of the configuration file for
the phone.
Table 7-2 Status Messages on the Cisco Unified IP Phone (continued)
Message Description Possible Explanation and Action
Table 7-3 Network Statistics Message Components
Item Description
Rx Frames Number of packets received by the phone
Tx Frames Number of packets sent by the phone
Rx Broadcasts Number of broadcast packets received by the phone
