7-13
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 8.5
OL-23092-01
Chapter 7 Viewing Model Information, Status, and Statistics on the Cisco Unified IP Phone
Status Menu
Firmware Versions Screen
The Firmware Versions screen displays information about the firmware version that is running on the
phone. Table 7-4 explains the information that is displayed on this screen.
To display the Firmware Version screen, follow these steps:
Procedure
Step 1 Press the Settings button.
Step 2 Select Status.
Step 3 Select Firmware Versions.
IPv6 Information on the DHCPv6 status. This includes the following
states:
• DHCP6 BOUND;
• DHCP6 DISABLED
• DHCP6 RENEW
• DHCP6 REBIND
• DHCP6 INIT
• DHCP6 SOLICIT
• DHCP6 REQUEST
• DHCP6 RELEASING
• DHCP6 RELEASED
• DHCP6 DISABLING
• DHCP6 DECLINING
• DHCP6 DECLINED
• DHCP6 INFOREQ
• DHCP6 INFOREQ DONE
• DHCP6 INVALID
• DHCP6 DECLINED DUPLICATE IP
• DHCP6 WAITING COLDBOOT TIMEOUT
• DHCP6 TIMEOUT USING RESTORED VAL
• DHCP6 TIMEOUT. CANNOT RESTORE
• STACK TURNED OFF
Table 7-3 Network Statistics Message Components (continued)
Item Description
