Specifications

8-4
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 8.5
OL-23092-01
Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Configuring the Cisco Unified IP Phone to use HTTP/HTTPS Protocols
Configuring the Cisco Unified IP Phone to use HTTP/HTTPS
Protocols
The Cisco Unified IP Phone can be configured to use:
• The HTTPS protocol only
• The HTTP or HTTPS protocols
If your Cisco Unified IP Phone is configured to use the HTTP or HTTPS protocols (the second case
above), use http://<IP_address> or https://<IP_address> for the phone’s web access.
Device Information
The Device Information area on a phone’s web page displays device settings and related information for
the phone. Table 8-1 describes these items.
To display the Device Information area, access the web page for the phone as described in the Accessing
the Web Page for a Phone, page 8-2, and then click the Device Information hyperlink.
Table 8-1 Device Information Area Items
Item Description
MAC Address Media Access Control (MAC) address of the phone
Host Name Unique, fixed name that is automatically assigned to the phone based on its
MAC address
Phone DN Directory number assigned to the phone
App Load ID Identifier of the firmware running on the phone
Boot Load ID Identifier of the factory-installed load running on the phone
Version Version of the firmware running on the phone
Expansion Module 1 Phone load ID for the first Cisco Unified IP Phone Expansion Module.
Expansion Module 2 Phone load ID for the second Cisco Unified IP Phone Expansion Module.
Hardware Revision Revision value of the phone hardware
Serial Number Serial number of the phone.
Model Number Model number of the phone.
Message Waiting Indicates if there is a voice message waiting on any line for this phone.
