Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Configuration
Network Configuration
The Network Configuration area on a phone’s web page displays network configuration information and
information about other phone settings. Table 8-2 describes this information.
You can view and set many of these items from the Network Configuration Menu and the Device
Configuration Menu on the Cisco Unified IP Phone. For more information, see Chapter 5, Configuring
Features, Templates, Services, and Users.
To display the Network Configuration area, access the web page for the phone as described in the
Chapter 8, Accessing the Web Page for a Phone, and then click the Network Configuration hyperlink.
UDI Displays the following Cisco Unique Device Identifier (UDI) information
about the phone:
• Device Type—Indicates hardware type. For example, phone displays for
all phone models.
• Device Description—Displays the name of the phone that is associated
with the indicated model type.
• Product Identifier—Specifies the phone model.
• Version Identifier—Represents the hardware version of the phone.
The Version Identifier field might display blank if using an older model
Cisco Unified IP Phone because the hardware does not provide this
information.
• Serial Number—Displays the phone’s unique serial number.
Time Time obtained from the Date/Time Group in Cisco Unified Communications
Manager to which the phone belongs.
Time Zone Timezone obtained from the Date/Time Group in Cisco Unified
Communications Manager to which the phone belongs.
Date Date obtained from the Date/Time Group in Cisco Unified Communications
Manager to which the phone belongs.
LLDP: PC Port Indicates whether Link Layer Discovery Protocol (LLDP) is enabled on the PC
port.
LLDP-MED: SW
Port
Indicates whether Link Layer Discovery Protocol Media Endpoint Discovery
(LLDP-MED) is enabled on the switch port.
Table 8-1 Device Information Area Items (continued)
Item Description
Table 8-2 Network Configuration Area Items
Item Description
DHCP Server IP address of the Dynamic Host Configuration Protocol (DHCP) server
from which the phone obtains its IP address.
BOOTP Server Indicates whether the phone obtains its configuration from a Bootstrap
Protocol (BootP) server.
MAC Address Media Access Control (MAC) address of the phone.
