Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Configuration
Host Name Host name that the DHCP server assigned to the phone.
Domain Name Name of the Domain Name System (DNS) domain in which the phone
resides.
IP Address Internet Protocol (IP) address of the phone.
Subnet Mask Subnet mask used by the phone.
TFTP Server 1 Primary Trivial File Transfer Protocol (TFTP) server used by the
phone.
Default Router 1–5 Default router used by the phone (Default Router 1) and optional
backup routers (Default Router 2–5.
DNS Server 1–5 Primary Domain Name System (DNS) server (DNS Server 1) and
optional backup DNS servers (DNS Server 2–5) used by the phone.
Operational VLAN ID Auxiliary Virtual Local Area Network (VLAN) configured on a Cisco
Catalyst switch in which the phone is a member.
Admin. VLAN ID Auxiliary VLAN in which the phone is a member.
Unified CM 1–5 Host names or IP addresses, in prioritized order, of the
Cisco Unified Communications Manager servers with which the
phone can register. An item can also show the IP address of an SRST
router that is capable of providing limited
Cisco Unified Communications Manager functionality, if such a router
is available.
For an available server, an item will show the
Cisco Unified Communications Manager server IP address and one of
the following states:
• Active—Cisco Unified Communications Manager server from
which the phone is currently receiving call-processing services.
• Standby—Cisco Unified Communications Manager server to
which the phone switches if the current server becomes
unavailable.
• Blank—No current connection to this
Cisco Unified Communications Manager server.
An item may also include the Survivable Remote Site Telephony
(SRST) designation, which identifies an SRST router capable of
providing Cisco Unified Communications Manager functionality with
a limited feature set. This router assumes control of call processing if
all other Cisco Unified Communications Manager servers become
unreachable. The SRST Cisco Unified Communications Manager
always appears last in the list of servers, even if it is active. You
configure the SRST router address in the Device Pool section in
Cisco Unified Communications Manager Configuration window.
Information URL URL of the help text that appears on the phone.
Directories URL URL of the server from which the phone obtains directory information.
Messages URL URL of the server from which the phone obtains message services.
Table 8-2 Network Configuration Area Items (continued)
Item Description
