Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Configuration
Services URL URL of the server from which the phone obtains Cisco Unified IP
Phone services.
DHCP Enabled Indicates whether DHCP is being used by the phone.
DHCP Address Released Indicates the setting of the DHCP Address Released option on the
phone’s Network Configuration menu.
Alternate TFTP Indicates whether the phone is using an alternative TFTP server.
Idle URL URL that the phone displays when the phone has not been used for the
time specified by Idle URL Time, and no menu is open.
Idle URL Time Number of seconds that the phone has not been used and no menu is
open before the XML service specified by Idle URL is activated.
Proxy Server URL URL of proxy server, which makes HTTP requests to non-local host
addresses on behalf of the phone HTTP client and provides responses
from the non-local host to the phone HTTP client.
Authentication URL URL that the phone uses to validate requests made to the phone web
server.
SW Port Configuration Speed and duplex of the switch port, where:
• A—Auto Negotiate
• 10H—10-BaseT/half duplex
• 10F—10-BaseT/full duplex
• 100H—100-BaseT/half duplex
• 100F—100-BaseT/full duplex
• 1000H—1000-BaseT/half duplex
• 1000F—1000-BaseT/full duplex
• No Link—No connection to the switch port
PC Port Configuration Speed and duplex of the switch port, where:
• A—Autonegotiate
• 10H—10-BaseT/half duplex
• 10F—10-BaseT/full duplex
• 100H—100-BaseT/half duplex
• 100F—100-BaseT/full duplex
• 1000H—1000-BaseT/half duplex
• 1000F—1000-BaseT/full duplex
• No Link—No connection to the PC port
To configure the setting on multiple phones simultaneously, configure
the Remote Port Configuration in the Enterprise Phone Configuration
(System > Enterprise Phone Configuration).
Note If the ports are configured for Remote Port Configuration in
Unified CM, the data cannot be changed on the phone.
Table 8-2 Network Configuration Area Items (continued)
Item Description
