Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Configuration
TFTP Server 2 Backup TFTP server that the phone uses if the primary TFTP server is
unavailable.
User Locale User locale associated with the phone user. Identifies a set of detailed
information to support users, including language, font, date and time
formatting, and alphanumeric keyboard text information.
Network Locale Network locale associated with the phone user. Identifies a set of
detailed information to support the phone in a specific location,
including definitions of the tones and cadences used by the phone.
Headset enabled Indicates whether the Headset button is enabled on the phone.
User Locale Version Version of the user locale loaded on the phone.
Network Locale Version Version of the network locale loaded on the phone.
PC Port Disabled Indicates whether the PC port on the phone is enabled or disabled.
Speaker Enabled Indicates whether the speakerphone is enabled on the phone.
GARP Enabled Indicates whether the phone learns MAC addresses from Gratuitous
ARP responses.
Video Capability Enabled Indicates whether the phone can participate in video calls when
connected to an appropriately equipped PC.
Voice VLAN Enabled Indicates whether the phone allows a device attached to the PC port to
access the Voice VLAN.
Auto Line Select Indicates whether the phone shifts the call focus to incoming calls on
all lines.
DSCP for Call Control DSCP IP classification for call control signaling.
DSCP for Configuration DSCP IP classification for any phone configuration transfer.
DSCP for Services DSCP IP classification for phone-based services.
Security Mode Displays the security mode that is set for the phone.
Web Access Enabled Indicates whether web access is enabled (Yes) or disabled (No) for the
phone.
Span to PC Port Indicates whether the phone will forward packets transmitted and
received on the network port to the access port.
PC VLAN VLAN used to identify and remove 802.1P/Q tags from packets sent to
the PC.
Forwarding Delay Indicates whether the internal switch begins forwarding packets
between the PC port and switched port on the phone when the phone
becomes active.
CDP: PC Port Indicates whether CDP is supported on the PC port.
CDP: SW Port Indicates whether CDP is supported on the switch xport.
LLDP-MED: SW Port Indicates whether Link Layer Discovery Protocol Media Endpoint
Discovery (LLDP-MED) is enabled on the switch port.
LLDP: PC Port Indicates whether Link Layer Discovery Protocol (LLDP) is enabled
on the PC port.
Table 8-2 Network Configuration Area Items (continued)
Item Description
