Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Statistics
Network Statistics
These network statistics areas on a phone’s web page provide information about network traffic on the
phone:
• Ethernet Information area—Displays information about Ethernet traffic. Table 8-3 describes the
items in this area.
• Access area—Displays information about network traffic to and from the PC port on the phone.
Table 8-4 describes the items in this area.
• Network area—Displays information about network traffic to and from the network port on the
phone. Table 8-4 describes the items in this area.
To display a network statistics area, access the web page for the phone as described in the Accessing the
Web Page for a Phone, page 8-2, and then click the Ethernet Information, the Access, and or the
Network hyperlink.
LLDP Asset ID Identifies the asset ID assigned to the phone for inventory
management.
Wireless Headset Hookswitch
Control
Enables users to receive notifications of incoming calls and answer or
end calls while working in a wireless environment.
LLDP Power Priority Advertises the phone’s power priority to the switch, enabling the
switch to appropriately provide power to the phones. Settings include:
• Unknown—default
• Low
• High
• Critical
Table 8-2 Network Configuration Area Items (continued)
Item Description
Table 8-3 Ethernet Information Area Items
Item Description
Tx Frames Total number of packets transmitted by the phone
Tx broadcast Total number of broadcast packets transmitted by the phone
Tx multicast Total number of multicast packets transmitted by the phone
Tx unicast Total number of unicast packets transmitted by the phone
Rx Frames Total number of packets received by the phone
Rx broadcast Total number of broadcast packets received by the phone
Rx multicast Total number of multicast packets received by the phone
Rx unicast Total number of unicast packets received by the phone
RxPacketNoDes Total number of shed packets caused by no Direct Memory Access
(DMA) descriptor
