8-10
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 8.5
OL-23092-01
Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Network Statistics
Table 8-4 Access Area and Network Area Items
Item Description
Rx totalPkt Total number of packets received by the phone
Rx crcErr Total number of packets received with CRC failed
Rx alignErr Total number of packets received between 64 and 1522 bytes in length
that have a bad Frame Check Sequence (FCS)
Rx multicast Total number of multicast packets received by the phone
Rx broadcast Total number of broadcast packets received by the phone
Rx unicast Total number of unicast packets received by the phone
Rx shortErr Total number of FCS error packets or Align error packets received that
are less than 64 bytes in size
Rx shortGood Total number of good packets received that are less than 64 bytes size
Rx longGood Total number of good packets received that are greater than 1522 bytes
in size
Rx longErr Total number of FCS error packets or Align error packets received that
are greater than 1522 bytes in size
Rx size64 Total number of packets received, including bad packets, that are
between 0 and 64 bytes in size
Rx size65to127 Total number of packets received, including bad packets, that are
between 65 and 127 bytes in size
Rx size128to255 Total number of packets received, including bad packets, that are
between 128 and 255 bytes in size
Rx size256to511 Total number of packets received, including bad packets, that are
between 256 and 511 bytes in size
Rx size512to1023 Total number of packets received, including bad packets, that are
between 512 and 1023 bytes in size
Rx size1024to1518 Total number of packets received, including bad packets, that are
between 1024 and 1518 bytes in size
Rx tokenDrop Total number of packets dropped due to lack of resources (for example,
FIFO overflow)
Tx excessDefer Total number of packets delayed from transmitting due to medium
being busy
Tx lateCollision Number of times that collisions occurred later than 512 bit times after
the start of packet transmission
Tx totalGoodPkt Total number of good packets (multicast, broadcast, and unicast)
received by the phone
Tx Collisions Total number of collisions that occurred while a packet was being
transmitted
Tx excessLength Total number of packets not transmitted because the packet
experienced 16 transmission attempts
Tx broadcast Total number of broadcast packets transmitted by the phone
Tx multicast Total number of multicast packets transmitted by the phone
