Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Device Logs
Device Logs
The Device Logs area on a phone’s web page provides information you can use to help monitor and
troubleshoot the phone.
• Console Logs—Includes hyperlinks to individual log files. The console log files include debug and
error messages received on the phone.
• Core Dumps—Includes hyperlinks to individual dump files.
• Status Messages area—Displays up to the 10 most recent status messages that the phone has
generated since it was last powered up. You can also see this information from the Status Messages
screen on the phone. Table 7-2 describes the status messages that can appear.
To display the Status Messages, access the web page for the phone as described in the Accessing the
Web Page for a Phone, page 8-2, and then click the Status Messages hyperlink.
• Debug Display area—Displays debug messages that might be useful to Cisco TAC if you require
assistance with troubleshooting.
Neighbor Device ID Identifier of a device connected to this port
Neighbor IP Address IP address of the neighbor device
Neighbor Port Neighbor device port to which the phone is connected
LLDP FramesOutTotal Total number of LLDP frames sent out from the phone
LLDP AgeoutsTotal Total number of LLDP frames that have been time out in cache
LLDP FramesDiscardedTotal Total number of LLDP frames that are discarded when any of the
mandatory TLVs is missing or out of order or contains out of range
string length.
LLDP FramesInErrorsTotal Total number of LLDP frames that received with one or more
detectable errors
LLDP FramesInTotal Total number of LLDP frames received on the phone.
LLDP TLVDiscardedTotal Total number of LLDP TLVs that are discarded.
LLDP
TLVUnrecognizedTotal
Total number of LLDP TLVs that are not recognized on the phone.
CDP Neighbor Device ID Identifier of a device connected to this port discovered by CDP
protocol.
CDP Neighbor IP Address IP address of the neighbor device discovered by CDP protocol.
CDP Neighbor Port Neighbor device port to which the phone is connected discovered by
CDP protocol.
LLDP Neighbor Device ID Identifier of a device connected to this port discovered by LLDP
protocol.
LLDP Neighbor IP Address IP address of the neighbor device discovered by LLDP protocol.
LLDP Neighbor Port Neighbor device port to which the phone is connected discovered by
LLDP protocol.
Table 8-4 Access Area and Network Area Items (continued)
Item Description
