8-12
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 8.5
OL-23092-01
Chapter 8 Monitoring the Cisco Unified IP Phone Remotely
Streaming Statistics
Streaming Statistics
A Cisco Unified IP Phone can stream information to and from up to three devices simultaneously. A
phone streams information when it is on a a call or running a service that sends or receives audio or data.
The streaming statistics areas on a phone’s web page provide information about the streams. Most calls
use only one stream (Stream 1), but some calls use two or three stream. For example, a barged call uses
Stream 1 and Stream 2.
To display a Streaming Statistics area, access the web page for the phone as described in the Accessing
the Web Page for a Phone, page 8-2, and then click the Stream 1, the Stream 2, or the Stream 3
hyperlink (Cisco Unfed IP Phones 7975G, 7965G, and 7945G also include Stream 4 and Stream 5
hyperlinks).
Table 8-5 describes the items in the Streaming Statistics areas.
Table 8-5 Streaming Statistics Area Items
Item Description
Remote Address IP address and UDP port of the destination of the stream.
Local Address IP address and UPD port of the phone.
Start Time Internal time stamp indicating when Cisco Unified Communications
Manager requested that the phone start transmitting packets.
Stream Status Indication of whether streaming is active or not.
Host Name Unique, fixed name that is automatically assigned to the phone based
on its MAC address.
Sender Packets Total number of RTP data packets transmitted by the phone since
starting this connection. The value is 0 if the connection is set to
receive only mode.
Sender Octets Total number of payload octets transmitted in RTP data packets by the
phone since starting this connection. The value is 0 if the connection
is set to receive only mode.
Sender Codec Type of audio encoding used for the transmitted stream.
Sender Reports Sent
1
Number of times the RTCP Sender Reports have been sent.
Sender Report Time Sent
1
Internal time stamp indicating when a RTCP Sender Report was sent.
Rcvr Lost Packets Total number of RTP data packets that have been lost since starting
receiving data on this connection. Defined as the number of expected
packets less the number of packets actually received, where the
number of received packets includes any that are late or duplicate. The
value displays as 0 if the connection was set to send-only mode.
Avg Jitter Estimate of mean deviation of the RTP data packet inter-arrival time,
measured in milliseconds. The value displays as 0 if the connection
was set to send-only mode.
Rcvr Codec Type of audio encoding used for the received stream.
Rcvr Reports Sent
1
Number of times the RTCP Receiver Reports have been sent.
Rcvr Report Time Sent
1
Internal time stamp indicating when a RTCP Receiver Report was sent.
