Specifications

D-1
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 8.5
OL-23092-01
APPENDIX
D
Technical Specifications
The following sections describe the technical specifications for the Cisco Unified IP Phone 7970 Series.
• Physical and Operating Environment Specifications, page D-1
• Cable Specifications, page D-2
• Network and Access Port Pinouts, page D-3
Physical and Operating Environment Specifications
Table D-1 shows the physical and operating environment specifications for the Cisco Unified IP Phone.
Table D-1 Physical and Operating Specifications
Specification Value or Range
Operating temperature 32° to 104°F (0° to 40°C)
Operating relative humidity 10% to 95% (non-condensing)
Storage temperature 14° to 140°F (–10° to 60°C)
Height 9.07 in. (23.03 cm)
Width
For Cisco Unified IP Phone 7975G, 7965G, and 7945G:
10.82 in. (27.48 cm)
For Cisco Unified IP Phone 7971G-GE and 7970G:
10.5 in. (26.67 cm)
Depth
• 2.54 in. (6.45 cm)—with footstand fully closed
• 6.0 in. (15.24 cm)—with footstand fully open
• 3.54 in. (9.00 cm)—with optional wall mount kit (Cisco Unified
IP Phone 7975G, 7965G, and 7945G)
Weight 3.25 lb (1.47 kg)
