D-2
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 8.5
OL-23092-01
Appendix D Technical Specifications
Cable Specifications
Cable Specifications
• RJ-9 jack (4-conductor) for handset and headset connection.
• RJ-45 jack for the LAN 10/100/1000BaseT connection (labeled 10/100/1000 SW).
• RJ-45 jack for a second 10/100/1000BaseT compliant connection (labeled 10/100/1000 PC).
• 3.5 mm jack for microphone and speaker connection (for Cisco Unified IP Phone 7971G-GE and
7970G only).
• 48-volt power connector.
Power options Cisco Unified IP Phone 7975G, 7965G and 7945G:
• 100-240 VAC, 50-60 Hz, 0.5 A—when using the AC adapter
• 44V - 57V DC, 0.25 A—when using the in-line power over the
network cable
Cisco Unified IP Phone 7971G-GE and 7970G:
• The phone can receive power from IEEE 802.3af-compliant data
switches (Class III)
• The phone can be powered locally with a power adapter (Cisco
part number CP-PWR-CUBE-3=) and the appropriate power cord
(power requirements for the power adapter: 100-240 VAC, 50-60
Hz, 0.5 A)
Cables
For Cisco Unified IP Phone 7975G, 7965G, and 7945G:
• Category 3/5/5e/6 for 10-Mbps cables with 4 pairs
• Category 5/5e/6 for 100-Mbps cables with 4 pairs
• Category 5e/6 for 1000-Mbps cables with 4 pairs
Note Cables have 4 pairs of wires for a total of 8 conductors.
For Cisco Unified IP Phone 7971G-GE and 7970G:
• Category 3/5/5e for 10-Mbps cables with 4 pairs
• Category 5/5e for 100-Mbps cables with 4 pairs
• Category 5e/6 for 1000-Mbps cables with 4 pairs
Note Cables have 4 pairs of wires for a total of 8 conductors.
Distance requirements As supported by the Ethernet specification, it is assumed that the
maximum cable length between each Cisco Unified IP Phone and the
switch is 100 meters (330 feet).
Table D-1 Physical and Operating Specifications (continued)
Specification Value or Range
