Chapter 1 An Overview of the Cisco Unified IP Phone
Installing Cisco Unified IP Phones
5. When you are configuring the network settings on the
phone, for an IPv4 network you can set up an IP
address for the phone by either using DHCP or
manually entering an IP address.
Using DHCP—To enable DHCP and allow the DHCP
server to automatically assign an IP address to the
Cisco Unified IP Phone and direct the phone to a TFTP
server, choose Settings > Network Configuration>
IPv4 Configuration and configure the following:
• To enable DHCP, set DHCP Enabled to Yes.
DHCP is enabled by default.
• To use an alternate TFTP server, set Alternate
TFTP Server to Yes, and enter the IP address for
the TFTP Server.
Note Consult with the network administrator if you
need to assign an alternative TFTP server
instead of using the TFTP server assigned by
DHCP.
Without DHCP—You must configure the IP address,
subnet mask, TFTP server, and default router locally
on the phone, choose Settings > Network
Configuration> IPv4 Configuration:
To disable DHCP and manually set an IP address:
a. To disable DHCP, set DHCP Enabled to No.
b. Enter the static IP address for phone.
c. Enter the subnet mask.
d. Enter the default router IP addresses.
e. Set Alternate TFTP Server to Yes, a n d enter the
IP address for TFTP Server 1.
You must also enter the domain name where the phone
resides by Choosing Settings > Network
Configuration.
The Cisco Unified IP Phone supports having both IPv4
and an IPv6 address concurrently. You can configure
Cisco Unified Communications Manager to support
IPv4 addresses only, IPv6 addresses only, or support
both IPv4/IPv6 addresses.
See Configuring Startup Network Settings, page 3-15.
See Network Configuration Menu, page 4-5.
Table 1-8 Checklist for Installing the Cisco Unified IP Phones (continued)
Task Purpose For More Information
