Chapter 3 Setting Up the Cisco Unified IP Phone
Installing the Cisco Unified IP Phone
Figure 3-2 Cisco Unified IP Phone 7975G, 7971G-GE, and 7970G Rear Cable Connections
Cisco Unified IP Phone 7975G, 7971G-GE, and 7970G Rear Cable Connections:
1
130055
AUX
10/100/1000 SW 10/100/1000 PC
DC48V
7
5
4
3
2
6
1 DC adapter port (DC48V) 5 Access port
2 Power supply with DC Connector 6 Handset port
3 Power cable with AC wall plug 7 Headset port
4 Network port
