Chapter 3 Setting Up the Cisco Unified IP Phone
Adjusting the Placement of the Cisco Unified IP Phone
Procedure
Step 1 From Cisco Unified Communications Manager Administration, choose Device > Device Settings >
Phone Button Template.
Step 2 Click the Add New button.
Step 3 From the drop-down list, choose a template and click Copy.
Step 4 Rename the new template.
Step 5 Update the template to 56 Directory Numbers for Cisco Unified IP Phone 7975G, or 54 Directory
Numbers for Cisco Unified IP Phone 7965G.
Refer to Cisco Unified Communications Manager Administration Guide and Cisco Unified
Communications Manager System Guide for more information on creating and modifying templates.
Note You can also attach two Cisco Unified IP Phone Expansion Modules 7915s or two Cisco Unified
IP Phone Expansion Modules 7916s, to provide 48 additional lines or speed-dial and feature buttons.
Related Topics
• Before You Begin, page 3-1
• Adjusting the Placement of the Cisco Unified IP Phone, page 3-11
• Configuring Startup Network Settings, page 3-15
Adjusting the Placement of the Cisco Unified IP Phone
The Cisco Unified IP Phone includes an adjustable footstand. When placing the phone on a desktop
surface, you can adjust the tilt height to several different angles in 7.5 degree increments from flat to 60
degrees. You can also mount the phone to the wall by using the footstand or by using the optional locking
wall mount kit.
Adjusting Cisco Unified IP Phone Footstand and Phone Height
You can adjust the footstand adjustment plate on the Cisco Unified IP Phone to the height that provides
optimum viewing of the phone screen. See Figure 3-6 for more information.
Procedure
Step 1 Push in the footstand adjustment button.
Step 2 Adjust the footstand to the desired height.
