4-8
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 8.5
OL-23092-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Network Configuration Menu
PC Port
Configuration
Speed and duplex of the access port. Valid values:
• Autonegotiate
• 10 Half—10-BaseT/half duplex
• 10 Full—10-BaseT/full duplex
• 100 Half—100-BaseT/half duplex
• 100 Full—100-BaseT/full duplex
• 1000 Full—1000-BaseT/full duplex
If the phone is connected to a switch, configure the
port on the switch to the same speed/duplex as the
phone, or configure both to auto-negotiate.
If you change the setting of this option, you must
change the SW Port Configuration option to the same
setting.
1. Unlock network configuration options.
2. Scroll to the PC Port Configuration option
and then press the Edit softkey.
3. Scroll to the setting that you want and then
press the Select softkey.
4. Press the Save softkey.
To configure the setting on multiple phones
simultaneously, enable the Remote Port
Configuration in the Enterprise Phone
Configuration (System > Enterprise Phone
Configuration).
Note If the ports are configured for Remote
Port Configuration in Unified CM, the
data cannot be changed on the phone.
PC VLAN Allows the phone to interoperate with 3rd party
switches that do not support a voice VLAN. The
Admin VLAN ID option must be set before you can
change this option.
1. Unlock network configuration options.
2. Make sure the Admin VLAN ID option is
set.
3. Scroll to the PC VLAN option, press the
Edit softkey, and then enter a new PC
VLAN setting.
4. Press the Valida t e softkey and then press
the Save softkey.
VPN Shows the VPN (virtual private network) Client state:
• Connected
• Not Connected
(Supported only for the Cisco Unified IP Phone
7942G, 7945G, 7962G, 7965G, and 7975G.)
Display only—Cannot configure.
Table 4-2 Network Configuration Menu Options (continued)
Option Description To Change
