4-10
Cisco Unified IP Phone Administration Guide for Cisco Unified Communications Manager 8.5
OL-23092-01
Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Network Configuration Menu
DHCP Address
Released
Releases the IPv4 IP address assigned by DHCP. 1. Unlock network configuration options.
2. Scroll to the DHCP Address Released option
and press the Yes softkey to release the IP
address assigned by DHCP, or press the No
softkey if you do not want to release this IP
address.
3. Press the Save softkey.
DHCP Server IP address of the Dynamic Host Configuration
Protocol (DHCP) server from which the phone
obtains its IPv4 address.
Display only—Cannot configure.
Alternate TFTP Indicates whether the phone is using an alternative
TFTP server.
1. Unlock network configuration options.
2. Scroll to the Alternate TFTP option and press
the Yes softkey if the phone should use an
alternative TFTP server.
3. Press the Save softkey.
Table 4-3 IPv4 Configuration Menu Options (continued)
Option Description To Change
