Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Device Configuration Menu
SIP Configuration Menu for SIP Phones
The SIP Configuration menu is available on SIP phones. This menu contains these sub-menus:
• SIP General Configuration Menu, page 4-19
• Line Settings Menu for SIP Phones, page 4-20
SIP General Configuration Menu
The SIP General Configuration menu displays information about the configurable SIP parameters on a
SIP phone. Table 4-8 describes the options in this menu.
Table 4-8 SIP General Configuration Menu Options
Option Description To Change
Preferred CODEC Displays the CODEC to use when a call is
initiated. This value will always be set to none.
Display only—cannot configure.
Out of Band DTMF Displays the configuration of the out-of-band
signaling (for tone detection on the IP side of a
gateway). The Cisco Unified IP Phone (SIP)
supports out-of-band signaling by using the AVT
tone method. This value will always be set to avt.
Display only—cannot configure.
Register with Proxy This value will always be set to Yes. Display only—cannot configure.
Register Expires Displays the amount of time, in seconds, after
which a registration request expires.
From Cisco Unified Communications Manager
Administration, choose Device >
Device Settings > SIP Profile.
Phone Label Displays the text that is displayed on the top
right status line of the LCD on the phone. This
text is for end-user display only and has no effect
on caller identification or messaging. This value
will always be set to null.
Display only—cannot configure.
Enable VAD This value is set to No by default. From Cisco Unified Communications Manager
Administration, choose Device >
Device Settings > SIP Profile.
Start Media Port Displays the start Real-Time Transport Protocol
(RTP) range for media.
From Cisco Unified Communications Manager
Administration, choose Device >
Device Settings > SIP Profile.
End Media Port Displays the end Real-Time Transport Protocol
(RTP) range for media.
From Cisco Unified Communications Manager
Administration, choose Device >
Device Settings > SIP Profile.
NAT Enabled Displays if Network Address Translation (NAT)
is enabled. This value will always be set to false.
Display only—cannot configure.
NAT Address Displays the WAN IP address of the NAT or
firewall server. This value will always be set to
null.
Display only—cannot configure.
Call Statistics This value is set to No by default. From Cisco Unified Communications Manager
Administration, choose Device >
Device Settings > SIP Profile.
