Chapter 4 Configuring Settings on the Cisco Unified IP Phone
Device Configuration Menu
Related Topics
• Displaying a Configuration Menu, page 4-2
• Device Configuration Menu, page 4-17
Line Settings Menu for SIP Phones
The Line Settings menu displays information that relates to the configurable parameters for each of the
lines on a SIP phone. Table 4-9 describes the options in this menu.
Related Topics
• Displaying a Configuration Menu, page 4-2
• Device Configuration Menu, page 4-17
Call Preferences Menu for SIP Phones
The Call Preferences menu displays settings that relate to the settings for the call preferences on a SIP
phone. Table 4-10 describes the options in this menu.
Table 4-9 Line Settings Menu Options
Option Description To Change
Name Displays the lines and the number used to
register each line.
Use Cisco Unified Communications Manager
Administration to modify.
Short Name Displays the short name configured for the line. Use Cisco Unified Communications Manager
Administration to modify.
Longer Authentication
Name
Displays the name used by the phone for
authentication if a registration is challenged by
the call control server during initialization.
The length of the SIP digest authentication name
has been increased to 128 characters for Cisco
Unified 7900 Series SIP phones. The
authentication name is used to verify that the
phone is allowed to send SIP messages
(REGISTER, INVITE, and SUBSCRIBE) to the
Cisco Unified CM.
Use Cisco Unified Communications Manager
Administration to modify.
Display Name Displays the identification the phone uses for
display for caller identification purposes.
Use Cisco Unified Communications Manager
Administration to modify.
Proxy Address The value is left blank because it is not
applicable to SIP phones that are using Cisco
Unified Communications Manager.
Display only—Cannot configure.
Proxy Port The value is left blank because it is not
applicable to SIP phones that are using Cisco
Unified Communications Manager.
Display only—Cannot configure.
Shared Line Displays if the line is part of a shared line (Yes)
or not (No).
Display only—Cannot configure.
