Release Notes for Cisco 7000 Family for Cisco IOS Release 12.1 T
78-10811-05
New and Changed Information
New and Changed Information
The following sections list the new hardware and software features supported by the Cisco 7000 family
for Release 12.1 T.
New Software Features in Release 12.1(5)T1
There are no new software features supported in Cisco IOS Release 12.1(5)T1.
New Hardware Features in Release 12.1(5)T1
There are no new hardware features supported in Cisco IOS Release 12.1(5)T1.
New Software Features in Release 12.1(5)T
The following new software features are supported by the Cisco 7000 family for Cisco IOS
Release 12.1(5)T:
AutoInstall Using DHCP for LAN Interfaces
Platforms: Cisco 7100 series, Cisco 7200 series, and Cisco 7500 series routers
The AutoInstall Using DHCP for LAN Interfaces feature replaces the use of the Bootstrap Protocol
(BOOTP) with the use of the Dynamic Host Configuration Protocol (DHCP) for Cisco IOS AutoInstall
over LAN interfaces. AutoInstall is a Cisco IOS software feature that provides for the configuration of
a new routing device automatically when the device is initialized. DHCP (defined in RFC 2131) is based
on the Bootstrap Protocol, which provides the framework for passing configuration information to hosts
on a TCP/IP network. DHCP adds the capability of automatic allocation of reusable network addresses
and additional configuration options. In Cisco IOS Release 12.1(5)T, the IP address procurement phase
of the AutoInstall process is now accomplished using DHCP for Ethernet, Token Ring, and FDDI
WAN
CUG Selection Facility Suppress Option (5) Yes Yes Yes Yes
Frame Relay ELMI Address Registration (3) Yes Yes Yes Yes
Frame Relay PVC Interface Priority Queueing
1
(2) Yes Yes Yes Yes
Frame Relay Switching Enhancements: Shaping and
Policing
(2) Yes Yes Yes Yes
PPP over ATM SVC (3) Yes Yes Yes Yes
1. Support for Frame Relay PVC Interface Priority Queueing in RSP images is in nondistributed mode only.
Table 17 Feature List by Feature Set for the Cisco 7500 Series, Part 5 (continued)
Features In
Software Images by Feature Sets
Desktop/IBM
IPSec 56
Desktop/
IBM/FW/IDS
Desktop/
IBM/FW/IDS
IPSec 56
Desktop/
IBM/FW/IDS/
IP Sec 3DES
