Specifications
Table Of Contents
- Release Notes for Cisco7000 Family for CiscoIOS Release12.1 T
- Contents
- System Requirements
- Memory Requirements
- Hardware Supported
- Determining the Software Version
- Upgrading to a New Software Release
- Microcode Software
- Feature Set Tables
- Table4 Feature List by Feature Set for the Cisco7100 Series
- Table5 Feature List by Feature Set for the Cisco7100 Series, Part 2
- Table6 Feature List by Feature Set for the Cisco7100 Series, Part 3
- Table7 Feature List by Feature Set for the Cisco7200 Series
- Table8 Feature List by Feature Set for the Cisco7200 Series, Part 2
- Table9 Feature List by Feature Set for the Cisco7200 Series, Part 3
- Table10 Feature List by Feature Set for the Cisco7200 Series, Part 4
- Table11 Feature List by Feature Set for the Cisco7200 Series, Part 5
- Table12 Feature List by Feature Set for the Cisco7200 Series, Part 6
- Table13 Feature List by Feature Set for the Cisco7500 Series
- Table14 Feature List by Feature Set for the Cisco7500 Series, Part 2
- Table15 Feature List by Feature Set for the Cisco7500 Series, Part 3
- Table16 Feature List by Feature Set for the Cisco7500 Series, Part 4
- Table17 Feature List by Feature Set for the Cisco7500 Series, Part 5
- New and Changed Information
- New Software Features in Release12.1(5)T1
- New Hardware Features in Release12.1(5)T1
- New Software Features in Release12.1(5)T
- AutoInstall Using DHCP for LAN Interfaces
- CEF Switching for Routed Bridge Encapsulation
- Cisco 7200-I/O-GE+E and Cisco 7200-I/O-2FE/E Input/Output Controllers
- Cisco Quality of Service Device Manager 2.0 Support
- Class-Based Ethernet CoS Matching & Marking
- Class-Based Quality of Service Management Information Base
- Closed User Group Selection Facility Suppress Option
- Configurable per ATM-VC Hold Queue Size
- DiffServ Compliant WRED
- Distributed CRTP
- Distributed Low Latency Queuing
- Distributed Traffic Shaping
- FastEther Channel Enhancements on Cisco 7200 Series Routers
- Frame Relay Fragmentation with Hardware Compression
- Frame Relay Switching Diagnostics and Troubleshooting
- IGMP, Version 3
- Inter-Autonomous Systems MPLS VPN Support
- Interface Index Persistence
- Interface Range Specification
- Interworking Signalling Enhancements for H.323 and SIP VoIP
- IP DSCP Marking for Frame-Relay PVC
- MPLS Class of Service Enhancements
- MPLS Egress NetFlow Accounting
- MPLS Scalability Enhancements for LSC and ATM LSR
- MSDP MIB
- NAT—Enhanced H.225/H.245 Forwarding Engine
- NAT—Support of H.323 v2 Call Signalling (FastConnect)
- NAT—Support of IP Phone to Cisco Call Manager
- NAT—Support for NetMeeting Directory (Internet Locator Service—ILS)
- Network-Based Application Recognition
- NTP MIB
- Parser Cache
- PIM Dense Mode State Refresh
- PPPoE Radius Port Identification
- PPP Over Fast Ethernet 802.1Q
- Quality of Service for Virtual Private Networks
- Router-Port Group Management Protocol
- RSVP Support for Frame Relay
- SDLC SNRM Timer and Window Size Enhancements
- Set ATM CLP Bit
- TN3270 Server Connectivity Enhancements
- Traceroute Enhancement for MPLS
- Class Based Policer for the DiffServ AF PHB
- Turbo Access Control Lists
- VIP-Based Distributed FRF.11/12
- VIP-Based WFQ Support for RSVP
- VPN Accelerator Card Enhancements
- New Hardware Features in Release12.1(5)T
- Cisco7200-I/O-GE+E and Cisco7200-I/O-2FE/E Input/Output Controllers
- Dynamic Packet Transport OC-12c Port Adapter for 7200
- MIX-Enabled 2/4/8 Port Multichannel T1/E1 PortAdapter with CSU/DSU
- Multiport T1/E1 ATM Port Adapters with Inverse Multiplexing over ATM
- Network Services Engine
- NPE-400
- OC-12 Dynamic Packet Transport Interface Processor
- One-Port Enhanced ESCON Channel Port Adapter
- PA-GE Gigabit Ethernet Port Adapter
- PA-MC-T3+
- New Software Features in Release12.1(3)T
- Bridging Between IEEE 802.1Q vLANs
- CEF Support for IP Routing Between IEEE 802.1Q vLANs
- Circuit Interface Identification MIB
- Class-Based Marking
- Class-Based Shaping
- Event MIB
- Expression MIB Support of Delta, Wildcarding, and Aggregation
- Frame Relay ELMI Address Registration
- General Packet Radio Service Release 1.4
- HSRP Support for ICMP Redirects
- HSRP Support for MPLS VPNs
- Individual SNMP Trap Support
- MPLS Traffic Engineering and Enhancements
- PPP over ATM SVC
- RSVP Support for Low Latency Queuing
- Secure Shell, Version 1 Integrated Client
- SNMP Support for IOS vLAN Subinterfaces
- Source Specific Multicast
- Transparent Common Channel Signaling
- T.38 Fax Relay for Voice over IP H.323
- Virtual Switch Interface Master MIB
- WCCP Redirection on Inbound Interfaces
- New Hardware Features in Release12.1(3)T
- New Software Features in Release12.1(2)T
- AAA Server Group Deadtimer
- Bidirectional PIM
- Configurable Timers in H.225
- Ecosystem Gatekeeper Interoperability Enhancements, Phase 2
- Frame Relay PVC Interface Priority Queueing
- Frame Relay Switching Enhancements
- Gatekeeper-to-Gatekeeper Redundancy and Load-Sharing
- H.323 Support for Virtual Interfaces
- Low Latency Queueing for Frame Relay
- Minimum Masking Ability for NetFlow Router-Based Aggregation Schemes
- OSPF Flooding Reduction
- PRI QSIG on the Cisco 7200
- Virtual Profile CEF Switched
- Voice Over Frame Relay Configuration Enhancements
- New Hardware Features in Release 12.1(1)T
- New Software Features in Release12.1(1)T
- AAA Broadcast Accounting
- Answer Supervision Reporting
- CiscoH.323, Version 2, Phase 2
- COPS for RSVP
- Ecosystem Gatekeeper Interoperability Enhancements
- Gateway-to-Gatekeeper Billing Redundancy
- H.323 Version 2 Support
- IKE Extended Authentication
- ISDN Network Side for PRI for ETSI Net5 PRI
- PPPoE on ATM
- PGM Host
- Service Assurance Agent Enhancement
- SSH Version 1 Support for T Train
- Wildcard Pre-Shared Key Enhancement
- MIBs
- Important Notes
- Image Deferral, CiscoIOS Release 12.1(5)T1
- RSP-based MQC
- ICaveat CSCdr91706 and IOS HTTP Vulnerability
- Last Maintenance Release of Cisco IOS Release 12.1 T
- Image Deferral, CiscoIOS Release 12.1(3a)T2
- Image Deferral, Cisco IOS Release 12.1(3a)T1
- Image Deferral, CiscoIOS Release 12.1(3)T
- Cisco IOS Release 12.1(3)T and 12.1(3a)T1 Voice Issues
- Cisco IOS Software Product Numbering Change Announcement
- Caveats
- Related Documentation
- Obtaining Documentation
- Obtaining Technical Assistance
57
Release Notes for Cisco 7000 Family for Cisco IOS Release 12.1 T
78-10811-05
New and Changed Information
NAT—Support of IP Phone to Cisco Call Manager
Platforms: Cisco 7200 series and Cisco 7500 series routers
Cisco IP Phones use the Selsius Skinny Station Protocol to connect with and register to the Cisco Call
Manager (CCM). Messages flow back and forth that include IP address and Port information which is
used to identify other IP Phone users with which a call can be placed.
To be able to deploy Cisco IOS Network Address Translation (NAT) between the IP Phone and CCM in
a scalable environment, NAT needs to be able to detect the Selsius Skinny Station Protocol and
understand the information passed within the messages.
When an IP Phone attempts to connect to the CCM and it matches the configured NAT translation rules,
NAT will translate the original source IP address and replace it with one from the configured pool. This
new address is what will be reflected in the CCM and be visible to other IP Phone users.
NAT—Support for NetMeeting Directory (Internet Locator Service—ILS)
Platforms: Cisco 7100 series, Cisco 7200 series, and Cisco 7500 series routers
Microsoft NetMeeting is a Windows-based application that enables multi-user interaction and
collaboration from a users PC over the Internet or an intranet. Support for the NetMeeting Directory
(ILS) allows connections by name from the directory built into the NetMeeting application. Destination
IP addresses do not need to be known in order for a connection to be made.
Network-Based Application Recognition
Platforms: Cisco 7100 series and Cisco 7200 series routers
Network-Based Application Recognition (NBAR) is a classification engine that recognizes a wide
variety of applications, including Web-based and other difficult-to-classify protocols that utilize
dynamic TCP/UDP port assignments. When an application is recognized and classified by NBAR, a
network can invoke services for that specific application. NBAR ensures that network bandwidth is used
efficiently by working with QoS features to provide bandwidth guarantees and limits, traffic shaping,
and packet marking.
NBAR introduces several new classification features:
• Classification of applications which dynamically assign TCP/UDP port numbers
• Classification of HTTP traffic by URL, HOST, or MIME type
• Classification of Citrix ICA traffic by application name
• Classification of application traffic using subport information
NBAR can also classify static port protocols. Although Access Control Lists (ACLs) can also be used
for this purpose, NBAR is easier to configure and can provide classification statistics that are not
available when using ACLs.
NBAR provides a special Protocol Discovery feature that determines which application protocols are
traversing a network at any given time. The Protocol Discovery feature captures key statistics associated
with each protocol in a network. These statistics can be used to define traffic classes and QoS policies
for each traffic class.
For additional information on NBAR, see the Network-Based Application Recognition feature module
on Cisco.com and the Documentation CD-ROM.
