Specifications
Table Of Contents
- Release Notes for Cisco7000 Family for CiscoIOS Release12.1 T
- Contents
- System Requirements
- Memory Requirements
- Hardware Supported
- Determining the Software Version
- Upgrading to a New Software Release
- Microcode Software
- Feature Set Tables
- Table4 Feature List by Feature Set for the Cisco7100 Series
- Table5 Feature List by Feature Set for the Cisco7100 Series, Part 2
- Table6 Feature List by Feature Set for the Cisco7100 Series, Part 3
- Table7 Feature List by Feature Set for the Cisco7200 Series
- Table8 Feature List by Feature Set for the Cisco7200 Series, Part 2
- Table9 Feature List by Feature Set for the Cisco7200 Series, Part 3
- Table10 Feature List by Feature Set for the Cisco7200 Series, Part 4
- Table11 Feature List by Feature Set for the Cisco7200 Series, Part 5
- Table12 Feature List by Feature Set for the Cisco7200 Series, Part 6
- Table13 Feature List by Feature Set for the Cisco7500 Series
- Table14 Feature List by Feature Set for the Cisco7500 Series, Part 2
- Table15 Feature List by Feature Set for the Cisco7500 Series, Part 3
- Table16 Feature List by Feature Set for the Cisco7500 Series, Part 4
- Table17 Feature List by Feature Set for the Cisco7500 Series, Part 5
- New and Changed Information
- New Software Features in Release12.1(5)T1
- New Hardware Features in Release12.1(5)T1
- New Software Features in Release12.1(5)T
- AutoInstall Using DHCP for LAN Interfaces
- CEF Switching for Routed Bridge Encapsulation
- Cisco 7200-I/O-GE+E and Cisco 7200-I/O-2FE/E Input/Output Controllers
- Cisco Quality of Service Device Manager 2.0 Support
- Class-Based Ethernet CoS Matching & Marking
- Class-Based Quality of Service Management Information Base
- Closed User Group Selection Facility Suppress Option
- Configurable per ATM-VC Hold Queue Size
- DiffServ Compliant WRED
- Distributed CRTP
- Distributed Low Latency Queuing
- Distributed Traffic Shaping
- FastEther Channel Enhancements on Cisco 7200 Series Routers
- Frame Relay Fragmentation with Hardware Compression
- Frame Relay Switching Diagnostics and Troubleshooting
- IGMP, Version 3
- Inter-Autonomous Systems MPLS VPN Support
- Interface Index Persistence
- Interface Range Specification
- Interworking Signalling Enhancements for H.323 and SIP VoIP
- IP DSCP Marking for Frame-Relay PVC
- MPLS Class of Service Enhancements
- MPLS Egress NetFlow Accounting
- MPLS Scalability Enhancements for LSC and ATM LSR
- MSDP MIB
- NAT—Enhanced H.225/H.245 Forwarding Engine
- NAT—Support of H.323 v2 Call Signalling (FastConnect)
- NAT—Support of IP Phone to Cisco Call Manager
- NAT—Support for NetMeeting Directory (Internet Locator Service—ILS)
- Network-Based Application Recognition
- NTP MIB
- Parser Cache
- PIM Dense Mode State Refresh
- PPPoE Radius Port Identification
- PPP Over Fast Ethernet 802.1Q
- Quality of Service for Virtual Private Networks
- Router-Port Group Management Protocol
- RSVP Support for Frame Relay
- SDLC SNRM Timer and Window Size Enhancements
- Set ATM CLP Bit
- TN3270 Server Connectivity Enhancements
- Traceroute Enhancement for MPLS
- Class Based Policer for the DiffServ AF PHB
- Turbo Access Control Lists
- VIP-Based Distributed FRF.11/12
- VIP-Based WFQ Support for RSVP
- VPN Accelerator Card Enhancements
- New Hardware Features in Release12.1(5)T
- Cisco7200-I/O-GE+E and Cisco7200-I/O-2FE/E Input/Output Controllers
- Dynamic Packet Transport OC-12c Port Adapter for 7200
- MIX-Enabled 2/4/8 Port Multichannel T1/E1 PortAdapter with CSU/DSU
- Multiport T1/E1 ATM Port Adapters with Inverse Multiplexing over ATM
- Network Services Engine
- NPE-400
- OC-12 Dynamic Packet Transport Interface Processor
- One-Port Enhanced ESCON Channel Port Adapter
- PA-GE Gigabit Ethernet Port Adapter
- PA-MC-T3+
- New Software Features in Release12.1(3)T
- Bridging Between IEEE 802.1Q vLANs
- CEF Support for IP Routing Between IEEE 802.1Q vLANs
- Circuit Interface Identification MIB
- Class-Based Marking
- Class-Based Shaping
- Event MIB
- Expression MIB Support of Delta, Wildcarding, and Aggregation
- Frame Relay ELMI Address Registration
- General Packet Radio Service Release 1.4
- HSRP Support for ICMP Redirects
- HSRP Support for MPLS VPNs
- Individual SNMP Trap Support
- MPLS Traffic Engineering and Enhancements
- PPP over ATM SVC
- RSVP Support for Low Latency Queuing
- Secure Shell, Version 1 Integrated Client
- SNMP Support for IOS vLAN Subinterfaces
- Source Specific Multicast
- Transparent Common Channel Signaling
- T.38 Fax Relay for Voice over IP H.323
- Virtual Switch Interface Master MIB
- WCCP Redirection on Inbound Interfaces
- New Hardware Features in Release12.1(3)T
- New Software Features in Release12.1(2)T
- AAA Server Group Deadtimer
- Bidirectional PIM
- Configurable Timers in H.225
- Ecosystem Gatekeeper Interoperability Enhancements, Phase 2
- Frame Relay PVC Interface Priority Queueing
- Frame Relay Switching Enhancements
- Gatekeeper-to-Gatekeeper Redundancy and Load-Sharing
- H.323 Support for Virtual Interfaces
- Low Latency Queueing for Frame Relay
- Minimum Masking Ability for NetFlow Router-Based Aggregation Schemes
- OSPF Flooding Reduction
- PRI QSIG on the Cisco 7200
- Virtual Profile CEF Switched
- Voice Over Frame Relay Configuration Enhancements
- New Hardware Features in Release 12.1(1)T
- New Software Features in Release12.1(1)T
- AAA Broadcast Accounting
- Answer Supervision Reporting
- CiscoH.323, Version 2, Phase 2
- COPS for RSVP
- Ecosystem Gatekeeper Interoperability Enhancements
- Gateway-to-Gatekeeper Billing Redundancy
- H.323 Version 2 Support
- IKE Extended Authentication
- ISDN Network Side for PRI for ETSI Net5 PRI
- PPPoE on ATM
- PGM Host
- Service Assurance Agent Enhancement
- SSH Version 1 Support for T Train
- Wildcard Pre-Shared Key Enhancement
- MIBs
- Important Notes
- Image Deferral, CiscoIOS Release 12.1(5)T1
- RSP-based MQC
- ICaveat CSCdr91706 and IOS HTTP Vulnerability
- Last Maintenance Release of Cisco IOS Release 12.1 T
- Image Deferral, CiscoIOS Release 12.1(3a)T2
- Image Deferral, Cisco IOS Release 12.1(3a)T1
- Image Deferral, CiscoIOS Release 12.1(3)T
- Cisco IOS Release 12.1(3)T and 12.1(3a)T1 Voice Issues
- Cisco IOS Software Product Numbering Change Announcement
- Caveats
- Related Documentation
- Obtaining Documentation
- Obtaining Technical Assistance
![](/manual/cisco/mc3810-16mb-flash-memory/specifications-english/images/img-7.png)
7
Release Notes for Cisco 7000 Family for Cisco IOS Release 12.1 T
78-10811-05
System Requirements
Hardware Supported
Note Cisco IOS Release 12.1(5)T1 supports Cisco 7200 series and Cisco 7500 series routers.
Cisco IOS Release 12.1(5)T supports the Cisco 7000 family:
• Cisco 7100 series routers (Cisco 7120 and Cisco 7140)
• Cisco 7200 series routers (Cisco 7202, Cisco 7204, and Cisco 7206)
• Cisco 7500 series routers (Cisco 7505, Cisco 7507, Cisco 7513, and Cisco 7576)
• Cisco 7000 series routers (Cisco 7000 and Cisco 7010) upgraded with the 7000 Series Route
Switch Processor (RSP7000) and 7000 Series Chassis Interface (RSP7000CI)
Note Cisco IOS Release 12.1(5)T does not support the VIP2-10, VIP2-15, VIP2-20, or
VIP2-40.
For detailed descriptions of the new hardware features, see “New and Changed Information” section on
page 48.
Enterprise Firewall
Standard Feature
Set
Enterprise/FW/IDS rsp-jo3sv-mz 20 MB Flash 128 MB
DRAM
RAM
Enterprise/FW/IDS
IPSec 56
rsp-jo3sv56i-mz 20 MB Flash 128 MB
DRAM
RAM
Enterprise/FW/IDS
IPSec 3DES
rsp-jk2o3sv-mz 20 MB Flash 128 MB
DRAM
RAM
Enterprise/SNASW
Feature Set
Enterprise/SNASW rsp-a3jsv-mz 20 MB Flash 128 MB
DRAM
RAM
Enterprise/SNASW
IPSec 56
rsp-a3jsv56i-mz 20 MB Flash 128 MB
DRAM
RAM
Enterprise/SNASW
IPSec 3DES
rsp-a3jk2sv-mz 20 MB Flash 128 MB
DRAM
RAM
Desktop/IBM
Standard Feature
Set
Desktop/IBM rsp-dsv-mz 20 MB Flash 128 MB
DRAM
RAM
Desktop/IBM IPSec 56 rsp-dsv56i-mz 20 MB Flash 128 MB
DRAM
RAM
Desktop/IBM
Firewall Standard
Feature Set
Desktop/IBM/FW/IDS rsp-do3sv-mz 20 MB Flash 128 MB
DRAM
RAM
Desktop/IBM/FW/IDS
IPSec 56
rsp-do3sv56i-mz 20 MB Flash 128 MB
DRAM
RAM
Desktop/IBM/FW/IDS/
IPSec 3DES
rsp-dk2o3sv-mz 20 MB Flash 128 MB
DRAM
RAM
Table 2 Images and Memory Requirements for Cisco IOS Release 12.1(5)T (continued)
Platforms Feature Sets Image Name Software Image
Flash Memory
Recommended
DRAM Memory
Recommended
Runs
From
