Configuring Cisco Access Routers and the NME-WAE Network Module for ACNS Deployments April 14, 2008 This document describes how to configure the Cisco access router and the Cisco Wide Area Application Engine network module (NME-WAE) for Application and Content Networking System (ACNS) software deployments. The WAE network module is a standalone Wide Area Application Engine (WAE) that plugs into a host Cisco access router.
Prerequisites for Installing the Cisco WAE Network Modules • Glossary, page 37 • Related Documentation, page 38 • Obtaining Documentation, Obtaining Support, and Security Guidelines, page 39 Prerequisites for Installing the Cisco WAE Network Modules The prerequisites for installing the Cisco WAE network module in the access router are as follows: • Plan software upgrades or downgrades for times when you can take all applications that run on the host router offline.
Cisco WAE Network Module Hardware Description Because the network module does not have an external console port, you must configure the network module by initiating a Telnet session or by initiating a configuration session from the router CLI. • After initial setup, which requires using router configuration commands, you can configure the NME-WAE in the same manner as other ACNS devices, with the following exceptions: – The NME-WAE cannot serve as a Content Distribution Manager for other ACNS devices.
Cisco WAE Network Module Hardware Description Figure 1 NME-WAE Faceplate and LEDs NM-WAE-XXX-K9 XXX-XXXXX-XX XX LINK ACT Shut down application before removing or power cycling.
Setting Up Cisco WAE Network Modules and Opening a Session Hardware Interfaces The host router and network module use several interfaces for internal and external communication (see Figure 2). Each interface is configurable by using a IOS-like CLI. Figure 2 Router and Network Module Interface Host Router (Top View) 2 Router interface to module 3 Module interface to router 1 Router interface to external link 4 Module interface to external link On This Hardware Interface... Configure These Settings...
Setting Up Cisco WAE Network Modules and Opening a Session If you lose power or connection during any of the following procedures, the software usually detects the interruption and tries to recover. If it fails to recover, reinstall the software using the boothelper. You can configure basic network parameters for the network module by using the CLI, which is described in this document. For additional configuration instructions, see the ACNS online help that is included with the software application.
Setting Up Cisco WAE Network Modules and Opening a Session Detailed Steps From the host router CLI, perform the following steps: Step 1 Procedure Command Enter privileged EXEC mode on the host router. Enter your password if prompted. enable Example: Router> enable Step 2 Enter global configuration mode on the host router.
Setting Up Cisco WAE Network Modules and Opening a Session Step 8 Procedure Command Save the router running configuration. copy running-config startup-config Example: Router# copy running-config startup-config Step 9 Display the router running configuration so that you can verify interface configurations.
Setting Up Cisco WAE Network Modules and Opening a Session Use the following commands from the Network Module Interface 4. Log in to the network module. 5. Perform configuration or other procedures by using the ACNS CLI. 6. Press Control-Shift-6 x. Use the following command from the host router CLI: 7.
Starting the Cisco WAE Network Module and Displaying Status Procedure Step 5 Step 6 Enter configuration commands on the module as needed. Command Example (Configuration): Configuration command choices are similar to those commands that are available on the router. Access global configuration mode by using the configure terminal command. Enter configuration commands. Then exit global configuration mode with the exit command and save your new configuration with the write command.
Starting the Cisco WAE Network Module and Displaying Status Accessing the ACNS Software on the Network Module You can access the ACNS software that runs on the network module by first accessing one of the following: • The router IOS command-line interface (CLI) to open a console session to the network module • The ACNS Content Distribution Manager graphical user interface (GUI) For details about configuring and maintaining your ACNS network, see the following documents: • Cisco Application and Content
Starting the Cisco WAE Network Module and Displaying Status Table 2 Common Shutdown and Startup Commands (continued) Configuration Mode Command Purpose Router# service-module integrated-service-engine slot/0 shutdown Shuts down the network module operating system gracefully. Use when removing or replacing a hot-swappable module during online insertion and removal (OIR).
Starting the Cisco WAE Network Module and Displaying Status Table 3 Common Verification and Troubleshooting Commands (continued) Configuration Mode Command Purpose Router# show interfaces Displays information about hardware interfaces, including the network and the disk. Router# show interfaces integrated-service-engine Displays information about the module side of the router-module interface. Router# show ntp status Displays information about the Network Time Protocol (NTP).
Starting the Cisco WAE Network Module and Displaying Status Table 3 Common Verification and Troubleshooting Commands (continued) Configuration Mode Command Purpose SE-Module# show tech-support Displays general information about the service module. This information is useful to Cisco technical support for problem diagnosis. SE-Module# show version Displays information about the loaded router software or network module bootloader version and also hardware and device information.
Command Reference Command Reference This section documents the module-specific IOS router commands that are used to configure the WAE network module from the router command-line interface (CLI). All other IOS software commands used with this feature are documented in the IOS Release 12.4(9) T command reference publication. The network module is also known as the integrated-service-engine within the IOS CLI.
interface integrated-service-engine interface integrated-service-engine To enter the interface configuration mode for an integrated-service-engine (ISE) network module, use the interface integrated-service-engine command in global configuration mode. interface integrated-service-engine slot/unit Syntax Description slot Slot number of the interface. unit Number of the daughter card on the network module. For ISE network modules, always use 0.
service-module integrated-service-engine default-boot service-module integrated-service-engine default-boot To configure the integrated-service-engine (ISE) network module to use the default BIOS and bootloader, use the service-module integrated-service-engine default-boot command in privileged EXEC mode. service-module integrated-service-engine slot/unit default-boot Syntax Description slot Slot number of the network module in the router chassis.
service-module integrated-service-engine reload service-module integrated-service-engine reload To perform a graceful shutdown and reboot of the integrated-service-engine (ISE) network module ACNS operating system, use the service-module integrated-service-engine reload command in privileged EXEC mode. service-module integrated-service-engine slot/unit reload Syntax Description slot Slot number of the network module in the router chassis. /unit Number of the daughter card on the network module.
service-module integrated-service-engine reset service-module integrated-service-engine reset To reset the integrated-service-engine (ISE) network module hardware, use the service-module integrated-service-engine reset command in privileged EXEC mode. service-module integrated-service-engine slot/unit reset Syntax Description slot Slot number of the network module in the router chassis. /unit Number of the daughter card on the network module. For ISE network modules, always use 0.
service-module integrated-service-engine reset Command Description show diag Displays controller information for ISE network modules. show interfaces integrated-service-engine Displays basic interface configuration information for ISE network modules.
service-module integrated-service-engine session service-module integrated-service-engine session To begin a configuration session with an integrated-service-engine (ISE) network module through a console connection, use the service-module integrated-service-engine session command in privileged EXEC mode. service-module integrated-service-engine slot/unit session [clear] Syntax Description slot Slot number of the network module in the router chassis.
service-module integrated-service-engine session The following example clears the session that had been used to configure the ISE in the network module in slot 2: Router# service-module integrated-service-engine 2/0 session clear [confirm] [OK] Related Commands Command Description enable Enters privileged EXEC mode. interface Configures an interface and enters interface configuration mode. show diag Displays controller information for a network module.
service-module integrated-service-engine shutdown service-module integrated-service-engine shutdown To gracefully shut down an integrated-service-engine (ISE) network module, use the service-module integrated-service-engine shutdown command in privileged EXEC mode. service-module integrated-service-engine slot/unit shutdown Syntax Description slot Slot number of the network module in the router chassis. /unit Number of the daughter card on the network module. For ISE network modules, always use 0.
service-module integrated-service-engine shutdown Command Description show diag Displays controller information for ISE network modules. show interfaces integrated-service-engine Displays basic interface configuration information for ISE network modules.
service-module integrated-service-engine statistics service-module integrated-service-engine statistics To display reset and reload information for an integrated-service-engine (ISE) network module and its IOS software, use the service-module integrated-service-engine statistics command in EXEC mode. service-module integrated-service-engine slot/unit statistics Syntax Description slot Slot number of the network module in the router chassis. /unit Number of the daughter card on the network module.
service-module integrated-service-engine status service-module integrated-service-engine status To display configuration information related to software on the integrated-service-engine (ISE) side of a network module, use the service-module integrated-service-engine status command in privileged EXEC mode. service-module integrated-service-engine slot/unit status Syntax Description slot Slot number of the network module in the router chassis. /unit Number of the daughter card on the network module.
service-module integrated-service-engine status Related Commands Command Description interface integrated-service-engine Configures an interface for ISE network modules and enters interface configuration mode. show diag Displays controller information for ISE network modules. show interfaces integrated-service-engine Displays basic interface configuration information for ISE network modules.
show controllers integrated-service-engine show controllers integrated-service-engine To display controller information for integrated-service-engine (ISE) network modules, use the show controllers integrated-service-engine command in privileged EXEC mode. show controllers integrated-service-engine slot/unit Syntax Description slot Slot number of the network module in the router chassis. /unit Number of the daughter card on the network module. For ISE network modules, always use 0.
show controllers integrated-service-engine Related Commands Command Description service-module external ipv6 address Configures an interface for ISE network modules and enters interface configuration mode. show interfaces integrated-service-engine Displays basic interface configuration information for ISE network modules.
show diag show diag To display hardware and diagnostic information for a networking device, a line card, a processor, a jacket card, a chassis, or a network module, use the show diag command in privileged EXEC configuration mode. show diag [slot] Syntax Description slot Defaults None (Optional) Slot number of the interface. If a slot number is not specified, diagnostic information for all slots is displayed. Privileged EXEC Command History Release Modification 11.1CA This command was introduced.
show diag Usage Guidelines Release Modification 12.0(31)S This command was integrated into IOS Release 12.0(31)S and the subslot slot/subslot keyword and arguments were added to support SIPs and SPAs on the 12000 series router. 12.4(4)T This command was implemented for the HWIC-1ADSL and HWIC-1ADSLI interface cards on the following platforms: 1800 (modular) series, 2800 series, and 3800 series routers. 12.
show diag Related Commands Command Description show controllers integrated-service-engine Displays controller information for integrated-service-engine network modules. show interfaces integrated-service-engine Displays basic interface configuration information for integrated-service-engine network modules.
show interfaces integrated-service-engine show interfaces integrated-service-engine To display basic interface configuration information for an integrated-service-engine (ISE) network module, use the show interfaces integrated-service-engine command in privileged EXEC mode. show interfaces integrated-service-engine slot/unit Syntax Description slot Slot number of the network module in the router chassis. /unit Number of the daughter card on the network module. For ISE network modules, always use 0.
show interfaces integrated-service-engine Table 6 show interfaces integrated-service-engine Field Descriptions (continued) Field Description rxload Receive load on the interface as a fraction of 255 (255/255 is completely saturated), calculated as an exponential average over 5 minutes. Encapsulation Encapsulation method that is assigned to the interface, ARPA in this case. loopback Indicates whether loopback is set.
show interfaces integrated-service-engine Table 6 show interfaces integrated-service-engine Field Descriptions (continued) Field Description 5 minute input rate, 5 minute output rate Average number of bits and packets transmitted per second in the last 5 minutes. If the interface is not in promiscuous mode, it senses network traffic that it sends and receives (rather than all network traffic).
show interfaces integrated-service-engine Table 6 show interfaces integrated-service-engine Field Descriptions (continued) Field Description overrun Number of times that the receiver hardware was unable to handle received data to a hardware buffer because the input rate exceeded the receiver’s ability to handle the data. ignored Number of received packets that were ignored by the interface because the interface hardware ran low on internal buffers.
Glossary Table 6 Related Commands show interfaces integrated-service-engine Field Descriptions (continued) Field Description deferred Indicates that the chip, while ready to transmit a frame, had to defer because the carrier was asserted. lost carrier Number of times that the carrier was lost during transmission. no carrier Number of times that the carrier was not present during the transmission.
Related Documentation NTP Network Time Protocol. Protocol built on top of TCP that ensures accurate local timekeeping with reference to radio and atomic clocks located on the Internet. This protocol is capable of synchronizing distributed clocks within milliseconds over long time periods. service (or services) engine Alternate term for service module with installed application software. syslog Industry-standard protocol for capturing log information for devices on a network.
