Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Introduction Configure your system The remote control Getting started guide The menu system The web interface Password protection Chapter 1 Introduction D14639.02 Profile Series, Codec C Series and Quick Set C20/C20 Plus Getting Started Guide TC4.0, November 2010. Copyright © 2010 Cisco Systems, Inc. All rights reserved. 3 www.cisco.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Introduction Introduction This document provides the information required to help you configure the basic settings on your video system. You will also learn about the web interface and find other information that can be useful in your daily use of your video system.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Configure your system Configure system The remote control Getting started guide The menu system The web interface Password protection Chapter 2 How to configure your system D14639.02 Profile Series, Codec C Series and Quick Set C20/C20 Plus Getting Started Guide TC4.0, November 2010. Copyright © 2010 Cisco Systems, Inc. All rights reserved. 5 www.cisco.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Configure your system Configure system Initial configurations When starting up the system for the first time, the menu password is not set. Read more about password protection in the Password protection section later in this guide. 1 The menu system The web interface Password protection Using the menu system Using the web interface The menus on screen are easy accessible.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents 5 Configure your system Configure system Introduction The remote control 6 Add the system to the network Contact your system administrator, or service provider, for information about the network settings: • For H.323 calls, this will include system name, H.323 alias, gatekeeper address, etc. • • The web interface Password protection Verify your settings Verify the settings by reviewing the System Information page. 1.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents 8 Introduction Configure your system Configure system The remote control Getting started guide The menu system The web interface Password protection Password protection of the Advanced menu It is recommended to define a password to protect the Advanced menu. Changing the advanced settings may affect the behavior of the system and should be done by the system administrator.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Configure your system The The remote remote control control Getting started guide The menu system The web interface Password protection Chapter 3 Using the remote control D14639.02 Profile Series, Codec C Series and Quick Set C20/C20 Plus Getting Started Guide TC4.0, November 2010. Copyright © 2010 Cisco Systems, Inc. All rights reserved. 9 www.cisco.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Using the remote control The Functions keys in the upper part of the remote control reflect the softkeys on screen. Configure your system The The remote remote control control Getting started guide The menu system FUNCTION KEYS: Each Function key corresponds to a softkey on the screen and represents shortcuts and advanced functions..
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Configure your system Getting started guide The The remote remote control control CALL KEY: Press the Call key to place a call, and to accept an incoming call. The menu system The web interface Password protection ALPHANUMERIC KEYPAD The keypad behaves in a similar way to the keypad of a cellular phone. Use the Call button as a shortcut to Recent Calls when the Call menu is not visible. 0-9, a-z, period (.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Configure your system The remote control Getting started guide The menu menu system The system The web interface Password protection Chapter 4 Using the menu system D14639.02 Profile Series, Codec C Series and Quick Set C20/C20 Plus Getting Started Guide TC4.0, November 2010. Copyright © 2010 Cisco Systems, Inc. All rights reserved. 12 www.cisco.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Configure your system The Home, Settings and Advanced menus are explained in the User guide for your product. Read about the daily use of your video system in the User guide for Profile Series, Codec C Series and Quick Set C20 / C20 Plus. The Advanced configuration menu is explained in the Administrator guide for your product. See the Administrator guide for Quick Set C20 / C20 Plus and Profile 42” using C20.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Configure your system The Advanced menu may be password protected. If so, type in the menu password and press OK to proceed or Cancel to go back to the Settings menu.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Configure your system The search functionality The remote control • • On the remote control, press the # key to toggle between lower or upper case characters and numbers: abc/123. Enter as many characters as needed until the name or setting you are searching for displays in the list. Add or remove characters until you get the desired result.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Configure your system The web interface Password protection HOME The Advanced menu can be password protected. Read more about password protection in chapter 6, Password protection. The menu menu system The system The remote control Setting the menu password When turning on the codec for the first time, the password is not set.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Configure your system The remote control Getting started guide The menu system The web interface interface The Password protection Chapter 5 Using the web interface D14639.02 Profile Series, Codec C Series and Quick Set C20/C20 Plus Getting Started Guide TC4.0, November 2010. Copyright © 2010 Cisco Systems, Inc. All rights reserved. 17 www.cisco.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction The web interface Configure your system The remote control Getting started guide The menu system The web interface interface The Password protection Signing in The web interface allows for remote administration of the system. 1. Enter the IP address of the codec. Connect to the codec Open a web browser and enter the IP address of the codec.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction System information Configure your system Getting started guide The remote control The menu system The web interface interface The The System Information page From the web interface you have the following menu options: • • • • • • • • • • • • • • • Password protection Current signed in user System Information Call Snapshot Users Change Password Wallpaper Logon Banner Upload Certificates Audit Certificate Logs XML F
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Making calls from the web interface Configure your system The remote control Getting started guide The menu system The web interface interface The Password protection The Call page How to make a call Sometimes, e.g. when you are configuring the system from a remote location, it is convenient to be able to make calls from the video system to ensure everything works as expected.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Changing your password Configure your system The remote control Getting started guide The menu system The web interface interface The Password protection The Change Password page When you are logged in, you can change your password. The password is a string with 0–255 characters. How to change your password 1. Enter your current password, your new password, and repeat the new password in the input fields. 2.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Custom wallpaper Configure your system The remote control Getting started guide The menu system The web interface interface The Password protection The Wallpaper page If you want the company logo or a custom picture to be displayed on screen, you may very well use a custom wallpaper. File format and picture size The picture file format for the custom wallpaper is PNG. The maximum size is 1920x1200pixels.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Support log files Configure your system The remote control Getting started guide The menu system The web interface interface The Password protection The Logs page The log files are Cisco specific debug files which may be requested by the Cisco support organization if you need technical support. Historical log files Current log files Time stamped historical log files.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Software upgrade Configure your system The remote control Getting started guide The menu system The web interface interface The Password protection The Upgrade Software page From this page you can do software upgrades and add a release key and option keys. Software versions The C series codecs are using the TC software. NOTE: Contact your system administrator if you have questions about the software version.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Advanced configuration Configure your system The remote control Getting started guide The menu system The web interface interface The Password protection The Advanced Configuration page The web interface allows for remote administration of the system. The Advanced configuration defines the system settings and are structured in a hierarchy, making up a database of system settings.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Restarting the system Configure your system The remote control Getting started guide The menu system The web interface interface The Password protection The Restart page Restarting the system takes a few minutes. Restarting the system Press Restart now. D14639.02 Profile Series, Codec C Series and Quick Set C20/C20 Plus Getting Started Guide TC4.0, November 2010. Copyright © 2010 Cisco Systems, Inc.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Configure your system The remote control Getting started guide The menu system The web interface Password Password protection protection Chapter 6 About password protection D14639.02 Profile Series, Codec C Series and Quick Set C20/C20 Plus Getting Started Guide TC4.0, November 2010. Copyright © 2010 Cisco Systems, Inc. All rights reserved. 27 www.cisco.
Profile Series, Codec C Series and Quick Set C20 / C20 Plus Contents Introduction Configure your system Password protection The system can be password protected in the following ways: • The Advanced menu can be password protected with a menu password. • The Codec is password protected. You always need to enter a username to log in. The same username and password is used for the web and command line interfaces.
