OWNERS MANUAL Version 3.
Safety information 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this item near moisture. Clean only with dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacture’s instructions. Do not install near any heat sources such as radiators, stoves or other items (including amplifiers) that produce heat.
CITRONIC MP-X10 Main features: 1 x USB front and 1 x USB rear inputs which can be read by both players simultaneously 2 x Large VFD displays which can be viewed from wide angles Plays MP3 files from either USB on the front or rear ports on either side of the player Easy-to-use folder and file search MP3/WAV compatible (ID3 tags) Instant start (sound is produced immediately when the play button is pressed) 3 modes of operation (Vinyl, CD DJ and Auto cue
Setup 1. Before making or changing the connections, switch off the power and disconnect the power cord from the AV outlet. 2. We recommend to use high quality shielded audio cables when connecting input/output devices as it makes a huge difference in sound reproduction quality. 3. Do not use excessively long cables. Be sure the plugs and jacks are securely fastened. Loose connections cause hum, noise or intermittence that can damage your speakers. 4.
General Functions and Controls – Top panel 1. VFD DISPLAY – This high quality VFD display indicates all the functions, as they are occurring. The display icons are explained in the VFD display section (page 12) 2. SEAMLESS LOOP: a. IN – Pressing the IN button sets a CUE POINT without music interruption. This button is also used to set the starting point of a SEAMLESS LOOP. b. OUT - This button is used to set the ending point of a LOOP.
3. TRACK SEARCH – This knob has three functions: a. You can use this to select the next or previous track by turning the knob forwards or backwards. b. Holding down and turning the knob forwards or backwards will rapidly skip through the tracks on your USB memory device by 10 tracks per click. c. Press the TRACK KNOB will read the ID3 tags on the file. Switch between: File name / Title name / Artist / Album / Genre on the VFD display. 4.
8. JOG WHEEL a. The JOG WHEEL will act as a frame search control when the track in PAUSE or CUE mode, allowing you to set a starting point or CUE point. b. The JOG WHEEL also works as a pitch bend during playback. Turning the side of the JOG WHEEL (in any JOG MODE) and turning clockwise will increase the pitch percentage up to 100%, and turning the wheel counterclockwise will decrease the pitch percentage down to -100%. The pitch bend will be determined by how long you turn the JOG WHEEL continuously. c.
21. EFFECTS AND HOLD a. EFFECTS - The below buttons add effects to the music. The volume and length of the effects can be controlled by a combination of the PARAMETER BUTTONS and JOG WHEEL. i. ECHO – This button is used to add an ECHO effect to your output signal. ii. FLANGER – The FLANGER effect distorts the output signal and creates an effect similar to the frequency phasing in and out of each other. iii. FILTER – The FILTER effect tweaks the original sound to add different tonal definition. iv.
General Functions and Controls – Front Panel 1. MIC 1 JACK – This jack socket is used to connect a microphone to the mixer. Connect your microphone via 6.3mm jack. The volume output level for microphone will be controlled by its own respective VOLUME control. 2. MIC LEVEL CONTROL – These rotary knobs controls the output volume of MICROPHONE 1 & 2. However master volume is controlled by the MASTER VOLUME CONTROL on the mixer. 3.
General Functions and Controls – Mixer Panel 1. USB PORT 1 - This is the USB port where you insert your USB 2.0 mass storage device (up to 32Gb). 2. MASTER VOLUME CONTROL – This rotary knob is used to control the master output level (volume). To avoid distorted output try to maintain an average output signal level +4 dB. NOTE: Be sure this volume control is always set to zero before turning the unit on. 3. BOOTH CONTROL – This rotary knob is used to adjust the level of the BOOTH outputs. 4.
12. CHANNEL GAIN CONTROL – This adjustment is used to adjust an audio signal input gain for a channel. Never use the gain control to adjust output volume. Set the gain level properly will ensure a clean output signal. 13. SOURCE SELECTOR – These switches are used to select the input source assigned to each channel. Each channel may only be assigned one input source at a time. a. CH1 & CH2 both set to PC – the entire unit works as a MIDI controller. b.
8. LINE/PHONO SELECTOR SWITCH – These switches are used to change the voltage line levels of there respected LINE/PHONO RCA inputs jacks. When connecting turntables that do not have a built-in pre-amp to these jacks be sure the corresponding switch is in the PHONO” position, and when using line level input devices be sure the switch is in the LINE position. NOTE: Always be sure main power is shut off before changing the position of the Line Level Selector Switch. 9.
7. TIME METER - These indicators will detail the current minutes, seconds, and frames. The meter will display either the elapse or remaining time of a track. The display time will depend on the selected time function. The selected time function will be displayed on the left side of the TIME METER as remaining track time or elapsed track name. 8. TIME BAR INDICATOR - This bar gives a visual approximation of a track time. This bar will begin to flash when a track is ending. 9.
Internal Menu Hold down the FOLDER knob for 2 seconds to enter the internal menu, and turn FOLDER knob to search through the different menu. Turn the TRACK knob or JOG WHEEL to change the submenus Save and exit internal menu, turn the FOLDER knob to F. Exit & Save and press the TRACK knob. The display indicates “Saving” 1. PLAYLIST - Normal / Title / Artist / Album/ Genre (for USB). Use the DBbuilder software (see next section) in order to use the PLAYLIST type: a. Normal: This is the default setting.
Data Management DATABASE BUILDER: Database management software for the MP-X10 scans your USB device and writes contents files making it easy for you to search by Title, Artist, Album or Genre. Installation: Refer to the following figures for installing database management software on your computer. CPU: Intel Pentium 4, 1GHz processor or above, Intel Centrino Mobile Technology 1.
STEP 3: Click Install STEP 4: Processing STEP 5: Click finish Page 16 of 25
Scan and create: Refer to the following process for scanning and creating database. NOTE: For Vista users please right click the icon and select “RUN AS ADMINISTRATOR” STEP 1: Select the desired storage device and click build STEP 2: Processing STEP 3: Complete NOTE: Please re-create the database builder whenever you change the contents of your USB device. PLAYLIST OPERATION: 1. 2. 3. Hold the FOLDER knob down for 3 seconds to enter the internal menu. Rotate the FOLDER knob to find the PLAYLIST option.
Specification: 1. 2. GENERAL SECTION PRODUCT: POWER SOURCE: POWER CONSUMPTION: DIMENSIONS: WEIGHT: MP-X10 Dual USB MP3 Player + Digital Mixer AC 100-240V, 60/50Hz 21 WATTS 420mm (W) X 298.8mm (D) X 89mm (H) 4.42kg INPUT/OUTPUT IMPEDANCE & SENSITIVITY: (EQ FLAT, MAXIMUM GAIN, LOAD=100KΩ) a. INPUT IMPEDANCE AND REFERENCE INPUT LEVEL LINE: 47K OHM /-14dBV (200mV) +/-0.1dB PHONO: 47K OHM /-50dBV (3.16mV) +/-0.1dB MIC: 10K OHM /-50dBV (3.16mV) +/-0.1dB b.
Cont. 10. TONE, EQ MIC: CHANNEL: -14 +/-3dB AT 100Hz -12 +/-3dB AT 10 KHz 10 +/-2dB, BELOW -30dB AT 70Hz 10 +/-2dB, BELOW -30dB AT 1 KHz 10 +/-2dB, BELOW -30dB AT 13 KHz 11. CHANNEL BALANCE Within 2dB 12. TALKOVER: -20dB +/- 2dB 13. USB HOST PLAYER: (SIGNAL FORMAT: MP3, 128KBPS) a. OUTPUT LEVEL: 0dBV +/-2dB (TCD782 TRK16, GAIN MAXIMUM, EQ FLAT) b. FREQUENCY RESPONSE: 17-16KHz +/-2dB (TCD781 TRK1,4,16, SET GAIN TO 0dBV OUT, EQ FLAT) c. THD+N: LESS THAN 0.
MIDI MAP FUNCTION Type FUNCTION CODE (DECK A) SW/ENC 05/17 SW/ENC 01/16 IN SW/LED 02/02 OUT SW/LED 03/03 SW/LED 04/04 SOURCE SELECT/U1 SW/LED 06/06 SAVE SW/LED 07/07 1 SW/LED (RED) 08/08 1 LED (GREEN) 2 SW/LED (RED) 2 LED (GREEN) 3 SW/LED (RED) 3 LED (GREEN) 4 SW/LED (RED) 4 LED (GREEN) CLEAR SW/LED 0C/0C SW/LED 0D/0D SW/LED 0E/0E 30 09/09 NOT E 44/56 40/55 D-1 41 D#1 42 E-1 43 F#1 45 G-1 46 G#1 47 C3 A-1 31 C#3 0A/0A A#1 32 0B/0B SHIFT (Hold
ECHO SW/LED 0F/0F FLANGER SW/LED 10/10 HOLD SW/LED 11/11 FILTER SW/LED 12/12 SKID SW/LED 13/13 RATIO Y SW/LED 14/14 %/ 16 SW/LED 15/15 SW 16 SW 17 A.
SW 62 23 67 PITCH BEND/28 62 7FH：ON 00H：OFF 67 7FH：ON 00H：OFF 60 VR:00~7F C2 61/63/68 VR:00~7F C#2 62/64/69 VR:00~7F D2 63/65/6A VR:00~7F 5F VR:00~7F 23 Pitch Silder VR/CENTER GAIN VR HIGH VR/SW/CENTER/LE D 12/24/29/ 24 C2 51/63/68 MID VR/SW/CENTER/LE D 13/25/2A/ 25 C#2 52/64/69 LOW VR/SW/CENTER/LE D 14/26/2B/ 26 D2 53/65/6A Channel Fader VR 10 U2 LED 2C 10 LED 2D 6 LED 2E LEVEL METER LED LEVEL METER LED 1 RELAY SW/LED 37/37 MASTER METER SW/LED 3
Fader Start ON(L) SW Fader Start OFF(L) SW Fader Start ON(R) SW Fader Start OFF(R) SW C.F CURVE (L) SW C.F CURVE (CENTER) SW C.
CC-ABSOLUTE (VR, LEVEL METER LED) TYPE Control Change messages are sent with status 0xBn, where n is the channel, for the specified CC controller. Thus the controller MIDI ID is indicated with the channel along with the CC number. The value from 0x00 to 0x7F, directly related to the location of the controller.
FOR MORE INFORMATION ON CITRONIC PRODUCTS VISIT WWW.CITRONIC.
