TVS5091 5” LCD Color TV OWNER’S MANUAL
INTRODUCTION The Clarion TVS5091 is a full-featured 5" LCD Color TV. It can be used as a stand-alone unit or integrated into a mobile multimedia system. ABOUT THE MANUAL AND WARRANTY To start enjoying your new Clarion TVS5091, please read the instructions listed in this manual. Keep all instructions for future reference. Please fill out and send in the enclosed warranty card to protect your purchase and aid in warranty service. Also, save your original sales receipt as proof of purchase.
• Do not disassemble or modify the set. Doing so may damage it and voids your warranty. •. Keep drinks and drops from umbrellas away from the set. Water may damage the internal circuitry • Do not let lit cigarettes or other hot objects touch the set. Doing so may damage or deform the cabinet. • Do not let the set become hot. If temperature in the car is high or the set has been exposed to direct sunlight and is hot, lower the temperature before using it.
BUTTON LOCATIONS 1 2 3 4 5 6 7 8 9 Power ON/OFF Switch DC Power Connector Diversity Input (Future Use) Internal Speaker FM Transmit Switch IR Remote Sensor Stand-By Indicator Rod Antenna Power Button 0 Auto Program Button q Input Selection Button w Picture Selection Button e Volume Up/Down Buttons r Channel Up/Down Buttons t Optional Antenna Input Connector y AV1 Input Connector u AV2 Input Connector i Earphone Connector 1 Number Pad 2 Skip 3 Erase/Write 4 Volume Up 5 Volume Down 6 TV/Video 7 Power 8 Cha
CAR STAND INSTALLATION 1. Choose the proper place to install. Make sure the surface is dry and clean. • If mounting on a flat surface, use a screwdriver to remove the two screws on the bottom of the stand to take away the support bracket. • If mounting on an angled surface, bend the support bracket to fit the curve of the install surface. 2. Tear off the protective paper of the adhesive tape from the car stand and press the stand to the install surface.
REMOTE CONTROL BATTERY INSTALLATION • Insert 2 AAA batteries into the compartment located on the back of the unit, following the polarities as shown. NOTES: • Each time you change the batteries, you must reprogram the unit. • We suggest you use alkaline batteries; do not use rechargeable batteries. • Always change all the batteries at the same time. INSTALLATION 1. One of the following power sources can be used. • AC Power Adapter • 12V Car Cord 2. Place the POWER ON/OFF switch to the "ON" position.
5. If the rod antenna is used, adjust the antenna direction to get the best reception. If unit is used in a vehicle, the Clarion ZCB301 Auxilliary TV Antenna is recommended to improve the reception. 6. Adjust the viewing angle. The recommended viewing angle of the TV unit is – 30 to +10 degrees vertical and +45 to –45 degrees horizontal. AUXILIAR Y VIDEO INPUTS OPERATION The TVS5091 is equipped with two auxiliary A/V Inputs. 1. Plug the AV1 Audio/Video Input cord into the AV1 Input jack. 2.
AUDIO ADJUSTMENT 1. Press the Volume Up and Down buttons on the unit or remote control to adjust the volume output level. 2. To mute the unit, press the Mute button on the remote control. Press button again to restore audio. FM TRANSMITTER When used in a vehicle that has a FM radio, the TVS5091 can broadcast audio which is received through the FM antenna of the radio. 1. Place the FM Transmit switch to the setting “1”. 2. Turn the car radio ON and tune the FM dial to 88.7.
Problem: No picture or sound on unit. Solution: • TV/AV1/AV2 mode may be selected incorrectly – Press the Input Selection button to the correct mode. • The TV and AV sources may be incorrectly connected – Check the connection and correct it. Problem: The picture is blurry and noisy. Solution: • The external antenna may not be properly connected or the rod antenna may not be extended – Check the connection and extend rod antenna. • The TV may not be properly tuned – Press the Auto Program button again.
Problem: Sound is poor with FM transmission (the TV sound through car audio system). Solution: • Make sure the FM transmitter is switched to setting 1 or 2 and the correct station for FM transmitter is set. (88.7 for setting 1 or 89.1 for setting 2) • The monitor may be too far away from the radio antenna. Adjust to bring it closer.
NOTES 11
661 W. Redondo Beach Blvd. Gardena, CA 90247 1-800-GO-CLARION www.clarion-usa.com TVS5091-10 Rev.
