ongratulations on your purchase of this Ungo System. Please read this manual thoroughly to familiarize yourself with your system’s components and operation. Discuss any questions you might have with your installing dealer. C Record the serial number of your Ungo system and keep all dealer records and receipts. Be sure to discuss the installation with the dealer so that you understand the specifics of the installation in your vehicle.
Table of Contents 1. About Your Ungo Security System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 1 2. Remote Transmitters Remote Transmitter Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 2 Optional Driver Door Priority Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 2 Battery Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
About Your Ungo Security System Ungo Security Systems are state-of-the-art vehicle protection systems equipped with features designed to: p Deter potential intrusions to the vehicle by continually flashing the system LED status indicator while the system is Armed, giving a visual indication to any passer-by that the vehicle is equipped with a security system. p Detect intrusions to the vehicle, including impacts to the vehicle’s body, and opening of the doors, trunk and hood.
Remote Transmitters Remote Transmitter Layout LED Button 1 Button 2 Button 3 Button 4 The Ungo MS2004 comes with 2 multi-function Remote Transmitters used to control nearly all of the system’s features. Each time a transmitter button is pressed, the LED will flash to indicate that a transmission is taking place. Button 1 Arms the system. This Button also locks the doors when the system is in Valet Mode. Button 2 Disarms the system. This Button also unlocks the doors when the system is in Valet Mode.
Battery Replacement Your Ungo Remote Transmitter uses a 12 volt alkaline battery, which will need to be replaced from time to time. Under normal conditions, the battery may last for up to a year before it needs replacement. When your Remote Transmitter’s battery is in need of replacement, you will notice a decrease in your system’s operating range or a decrease in the brightness of the Transmitter’s LED indicator.
Basic Features Remote Arming When Armed, the system monitors and protects 4 independent areas, or zones, including the doors, hood/trunk, shock sensor and optional sensor. To Arm the System: 1. Turn off the ignition. 2. Press Button 1. • • • • The siren/horn will chirp once.* The doors will lock. The parking lights will flash once. The LED will turn on red, indicating the doors, hood and trunk inputs are activated.
To Bypass the sensors: 1. After arming the system, press Button 1 again on the Remote Transmitter within 5 seconds. • The siren will chirp 5 times, indicating the sensors have been bypassed. 2. The sensors will remain bypassed until the next time the system is armed. Remote Disarming To Disarm the System: Press Button 2. • The siren/horn will chirp twice.* • The doors will unlock. • The parking lights will flash twice.** • The LED will turn off.
Arming Mode Selection Your system can be set in one of the following Arming Modes: • Passive (automatic) Arming with chirp confirmation • Active Arming (by Remote Only) • Passive (automatic) Arming without chirp confirmation To set the Arming Mode: 1. Turn the ignition on. 2. Within 4 seconds, press Button 3 to change the setting. one chirp two chirps three chirps = = = Passive Arming with chirp Active Arming Passive without chirp 3. Turn the ignition off to save your selection.
To enter Panic Mode: 1. Press and hold Button 1 for 3 seconds. • The siren will sound. • The doors will unlock. 2. Press Button 1 again to stop panic and place system into the Armed state. 3. Press Button 2 to stop panic and place system into the Disarmed state. If Panic Mode is not stopped by the Remote, it will automatically time out after 40 seconds, and the system will return to its prior Armed/Disarmed state.
6. Enter the code again and hold for 10 seconds on the last press. • The siren will chirp 3 times. • The parking lights will flash 3 times. • The LED will flash a number of times equal to the new code. 7. Release the switch. 8. Turn off the ignition. Automatic System Rearming This feature, which can be turned on by your installer during the installation, insures the security of the system by protecting your car in case of an accidental disarm.
Other Features Valet Mode Allows you to temporarily disable the security system when the car is being service or turned over to a parking attendant. To turn Valet Mode on or off: 1. Turn on the ignition. 2. Press and hold the override switch. 3. While holding the override switch, turn off the ignition. • The siren will chirp once to indicate you have turned Valet Mode on. • The siren will chirp twice to indicate you have turned Valet Mode off. 4. Release the override switch.
Dome Light Control For increased safety and convenience this optional feature will automatically turn on the dome light when you Disarm the system. With this feature installed, the dome light will turn on for 30 seconds when the system is disarmed (or unlocked in Valet Mode) using the Remote Transmitter.
Remote Car Starter When an optional Remote Car Starter is installed into your car, the Remote Transmitter can be used to remotely start and run your vehicle to warm-up the engine, as well as activate the heating / air conditioning system. Additional Remote Transmitters Additional Remote Transmitters for your MS2004 are available from your Authorized Ungo dealer. Status Indications You can use this chart to quickly identify and interpret your system’s chirp indications and LED flashes.
Notes Page 12 - MS2004 Owner’s Manual
Notes MS2004 Owner’s Manual - Page 13
Technical Data FCC ID: Specifications Main Unit Voltage: 12v, negative ground Current Consumption: <15mA Temperature Range: -40oF to +257 oF Auxiliary Output Capability: 500mA Internal Relays: (1) 30A, (3) 15A Transmitter Current Consumption: <.00mA, standby Battery Type: miniature 12v, type 23A MP62ZUUNGO701-702 HP92VUUNGO7000-2 THIS DEVICE COMPLIES WITH FCC RULES PART 15.
Warranty Information 1. Ungo Security Corporation of Gardena, California ("Ungo Security") warrants this Ungo system to be free from defects in materials and workmanship and to comply with Ungo Security’s applicable printed specifications. 2. Ungo Security systems carry a limited lifetime warranty on the Main unit (system brain) and transmitters.
Ungo Security Corporation A Clarion Company 661 West Redondo Beach Blvd. Gardena, CA 90247 800-Go-Clarion www.clarion-usa.com © Ungo Security Corporation, Gardena, CA 97-MS2004-10 Rev.
