4 LIGHT INTELLI-TANK

WITH 1-WIRE AND CAN COMMUNICATION

OPERATION MANUAL

FORM-ENG-0018 REV A 06-02-03

Summary of content (24 pages)

PAGE 1
FORM-ENG-0018 REV A 06-02-03 ISO 9001 CERTIFIED 607 NW 27th Ave Ocala, FL 34475 Phone: (352) 629-5020 or 800-533-3569 Fax: (352)-629-2902 SUITABLE FOR EXTERNAL DISTRIBUTION OPERATION MANUAL 4 LIGHT INTELLI-TANK WITH 1-WIRE AND CAN COMMUNICATION
PAGE 2
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 1. PRODUCT GROUP PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 1 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN REVISION LOG ..............................................................................................................................................
PAGE 3
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 PRODUCT GROUP Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 1. 2. PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 2 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN Revision Log Rev 1.00 Date 12-12-2005 Approved Changes Initial requirements 1.10 2-26-2007 AK Added CAN harness part numbers 1.
PAGE 4
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 3. SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 3 of 22 DATE 10/23/2007 REV 1.20 BY AMS PRODUCT GROUP PRODUCT ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN Operation 3.1. LED indications The ITL display uses the 4 LEDs to show the unit status (section 3.1.1), water level (section 3.1.
PAGE 5
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 3.1.3. PRODUCT GROUP PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 4 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN Error indications Condition Visual Invalid calibration Incomplete calibration EEPROM error Transducer signal voltage above 4.
PAGE 6
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 3.2. PRODUCT GROUP PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 5 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN Magnetic switches The display has two magnetic switches (left and right).
PAGE 7
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 PRODUCT GROUP Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 3.3. PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 6 of 22 DATE 10/23/2007 REV 1.
PAGE 8
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 PRODUCT GROUP Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 5. 6. 3.3.4. PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 7 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN Fill the tank to the three-quarter tank point and then activate the RIGHT switch.
PAGE 9
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 PRODUCT GROUP Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 8 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN A PASS condition is indicated when only the top LED (LED 4) is on. A FAIL condition exists if LED 4 is off and any other LED is on.
PAGE 10
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 PRODUCT GROUP PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 9 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN The CAN communication method is new for the ITL displays and is a more robust communication method.
PAGE 11
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 PRODUCT GROUP Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 4. PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 10 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN Password list DATASHEET P/N:114356 RLLR LRRL 1 point calibration (section 3.3.1) RLLR LLRL 2 point calibration (section 3.3.
PAGE 12
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 5. PRODUCT GROUP PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 11 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN Software revision check Hold a magnet on the LEFT magnetic switch while powering the display. The LEDs will display the software revision.
PAGE 13
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 6. 6.1. PRODUCT GROUP PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 12 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN Installation Cutout dimensions The display requires a cutout as shown.
PAGE 14
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 6.3. PRODUCT GROUP PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 13 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN Label orientation Before mounting the display and adhering the label insure that the display is situated correctly (TOP is UP).
PAGE 15
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 7. SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 14 of 22 DATE 10/23/2007 REV 1.20 BY AMS PRODUCT GROUP PRODUCT ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN Wiring 7.1.
PAGE 16
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 PRODUCT GROUP PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 15 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN 7.5. Communication wiring examples The displays can be set up to use the 1-wire or CAN communication methods.
PAGE 17
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 7.5.3. PRODUCT GROUP PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 16 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN CAN method, 1 master and 3 remotes System configured with CAN communication method. communicating with 3 remote displays (address 1). 7.5.4.
PAGE 18
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 7.5.5. PRODUCT GROUP PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 17 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN CAN method, pump sensor module and 1 remote System configured with CAN communication method.
PAGE 19
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 18 of 22 DATE 10/23/2007 REV 1.20 BY AMS PRODUCT GROUP PRODUCT ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN 7.6. System compatibility The ITL display is compatible with other Class 1 CAN and 1-wire products. 7.6.1.
PAGE 20
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 Condition Master Tank level unit does not change when actual tank level is changing. Remote Tank level unit does not follow Master display. SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 19 of 22 DATE 10/23/2007 REV 1.
PAGE 21
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 8.2. PRODUCT GROUP PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 20 of 22 DATE 10/23/2007 REV 1.
PAGE 22
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 PRODUCT GROUP Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 21 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN 10. Product specification 10.1.
PAGE 23
FORM-ENG-0018 REV A 05-27-03 607 NW 27th Ave Ocala, FL 34475 Ph: 352-629-5020 or 1-800-533-3569 Fax : 352-629-2902 or 1-800-520-3473 PRODUCT GROUP PRODUCT SUITABLE FOR EXTERNAL DISTRIBUTION PAGE OPERATION MANUAL 22 of 22 DATE 10/23/2007 REV 1.20 BY AMS ITL P/N 12V: 113739 ; 24V: 114378 4 LIGHT INTELLI-TANK DISPLAY WITH 1-wire and CAN 11. 板料信息声明 (RoHS 声明) – Declaration Information Sheet (RoHS Declaration) 11.1.
