4. Password list
RLLR LRRL
RLLR LLRL
1 point calibration (section 3.3.1)
2 point calibration (section 3.3.2)
RLLR LRLR 5 point calibration (section 3.3.3)
RLLR RLLR 9 point calibration (section 3.3.4)
RLLR LLRR Self test (section 3.4)
LRLR LRLR Configure display as Remote display (section 2.2)
RLLR LLLR Configure dim level (section 3.5)
LLRR LLRR Display voltage (section 8.2)
LRLL LLLR Configure for 1-wire communications (section 3.7)
LRLL LLRL Configure for CAN communications (section 3.7)
LRRR LLLL Configure as Master display with CAN address 1 (section 3.7.3)
LRRR LLLR Configure as Master display with CAN address 2 (section 3.7.3)
LRRR LRRR Configure as Master display with CAN address 3 (section 3.7.3)
LRRR LLRL Configure as Remote display with CAN address 1 (section 3.7.4)
LRRR LLRR Configure as Remote display with CAN address 2 (section 3.7.4)
LRRR LRRL Configure as Remote display with CAN address 3 (section 3.7.4)
LRRR LRLL
Configure as Remote display for use with Pump Sensor Module
(Tank 1)
LRRR RLRL
Configure as Remote display for use with Pump Sensor Module
(Tank 2)
LRRR RLRR
Configure as Remote display for use with Pump Sensor Module
(Tank 3)
