Digital Flowmeter Information
Operation
The flowmeter displays the current flow rate whenever the display has power and
the discharge is open. Range is 0 to 9995 GPM, LPM or IGPM as calibrated.
Totalizer
The display includes a totalizer function that displays the total amount of water
that has been flowed since the unit was turned on. This feature is enabled by
grounding terminal number eight (8) of the display connector.
While terminal number 8 is grounded, activating the left switch resets the totalizer
to zero (0).
The totalizer resets to zero whenever power is removed from the display.
Multiply the reading on the display by 100 (add two zeroes) for total flow.
