TM InTouch 510 Internet Call Waiting Alert Users Guide 1
Table of Contents If you have questions about the operation of your InTouch 510, be sure to check out the troubleshooting tips and FAQs beginning on page 11. More information can also be found on-line at www.classco.com Introduction ................................................................................... 4 Features ....................................................................................... 4 Installation ................................................................................
InTouchTM 510 Internet Call Waiting Alert Introduction With the InTouch 510, you’ll never miss another call while surfing the Internet. InTouch works with call waiting service from your local telephone company to detect and alert you to the presence of a call-waiting call while you’re online. You’ll know when someone’s trying to reach you when the unit flashes its LED and “beeps”. To connect the caller, answer the telephone plugged into the unit.
Installation In order to function, this product requires Call Waiting service from your local telephone company. Installation is easy. Simply follow these directions to install the unit and you can begin receiving calls while you’re on line. 1. Unplug your modem line cord from the wall. 2. If you have plugged a telephone into the modem or another wall outlet, unplug the telephone’s line cord now. 3. Connect the line cord that extends from the back of the unit to the telephone jack on your wall. 4.
Important Safety Instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. 2. 3. 4. 5. 6. 7. 8. 6 Read and understand all instructions. Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners; use a damp cloth for cleaning.
9. 10. 11. 12. 13. 14. Do not overload wall outlets and extension cords, as this can result in the risk of fire or electric shock. Never push objects of any kind into this product through cabinet slots, as they may touch dangerous voltage points or short out parts, resulting in the risk of fire or electric shock. Never spill liquid of any kind on the product.
Modem Settings Your InTouch 510 will identify incoming “call waiting” calls even when you’re online. Make sure your modem is connected to the jack on the back of your unit marked MODEM. And be sure your telephone is plugged into the jack on the back of the unit marked PHONE. (Do not plug your telephone into the phone jack on your modem. Doing so could cause the unit to operate improperly.) You will also need to verify two settings on your computer. 1. Make sure Call Waiting is not disabled.
2. If your computer modem is very sensitive to loss of carrier, you may need to modify the computer modem’s setup regis ter. From the Windows desktop, go to ‘My Computer’ and select the ‘Control Panel.’ Next select ‘Modems.’ From there, select ‘Properties’ followed by ‘Connection’ and ‘Advanced’. Then insert the following line into the field marked ‘Extra set tings.’ ATS10=255 (If you already have something in the dialog box, then add S10=255 to the end of it.
Operation Your modem session must be active for at least 60-seconds (allowing time for the modem connection to become stable) before the InTouch 510 can detect calls.
Troubleshooting and FAQs Have Questions? Before contacting ClassCo or your dealer, check the following list of suggestions. You might be able to solve the problem yourself. You can also find more trouble shooting tips on-line at www.classco.com Q: It’s not detecting call-waiting calls when I’m online Check your connections. Make sure your modem is plugged into the MODEM jack on the unit, and that the telephone line from the unit is plugged into your telephone wall jack.
Q: I hear modem tones when I answer the telephone Check your connections. Make sure your modem is plugged into the MODEM jack on the unit, and that the telephone line from the unit is plugged into your telephone wall jack. Make sure your telephone is plugged into the jack marked PHONE on the back of the IT510. Do not connect your telephone to the jack marked PHONE on your computer modem. The call can only be answered on the telephone plugged into the jacked marked PHONE on the back of the InTouch unit.
FCC Part 68 and ACTA Information Your caller ID unit has been registered with the Federal Communications Commission (FCC), and it complies with the standards set forth in part 68 of the FCC rules. The FCC requires that we provide the following information. Connection And Use: The FCC requires you to use a modular telephone jack. This equipment may not be used with party line service or coin-operated telephone lines.
FCC Part 15 Radio Interference Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate harmful radio frequency, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Manufacturers 1-Year Limited Warranty Who Is Covered? You must have proof of purchase to exchange the product. A sales receipt or other document showing the date that you pur chased the product is considered proof of purchase. What Is Covered? Coverage begins the day you buy your product. For one year thereafter, a defective or inoperative product will be replaced with a new, renewed or comparable product at no charge to you. A replacement product is covered only for the original warranty period.
FOR CUSTOMER SERVICE CALL CLASSCO TOLL FREE: (888) 252-7726 or visit product support on-line at www.classco.com Copyright © 2005 ClassCo Inc. All Rights Reserved Printed in China Rev.
