CD8620-Series/CD6620-Series

ClearCube Technology, Inc. www.clearcube.com (866) 652-3500 1 of 5

Overview

Package

Contents

 CD8620- or CD6620-series thin client

 Pedestal and thumb screw

 Power adapter and power cable

 This Quick Start Guide

Specifications

Processor: Intel Atom D2550 Dual Core 1.86 GHz

Chipset: Intel NM10

Memory: 1 × SODIMM, DDR3, up to 4 GB

Graphics: Integrated in Atom D2550

Audio: HD Audio VIA 1708S

Network: All models: 10/100/1000BASE-T Ethernet (RJ45)

CD6620-series also includes one of the following:

1000BASE-SX, LC connector (fiber SFP module)

10/100BASE-FX, LC connector (fiber SPF module)

1000BASE-T Ethernet (RJ45 SPF module)

Smart Card Reader: Models CD8624 and CD6624 only

BIOS: AMI UEFI BIOS (16 Mb SPI ROM)

USB: 4 × USB 2.0, 2 × USB 3.0

Storage: Flash SATA SSD module, up to 32 GB

Power: DC in 12 V/4 A external power adapter

Dimension: 230 mm (H) × 210 mm (D) × 57 mm (W)

Continued on next page

Summary of content (5 pages)

PAGE 1
CD8620-Series/CD6620-Series Overview Package Contents  CD8620- or CD6620-series thin client  Pedestal and thumb screw  Power adapter and power cable  This Quick Start Guide Specifications Processor: Intel Atom D2550 Dual Core 1.
PAGE 2
CD8620-Series/CD6620-Series Overview, Continued Features The pictures below show CD8620- and CD6620-series thin client features. Some features vary by model. Power button PS/2 port HDD activity USB 3.0 ports Network activity USB 2.0 ports Audio in Audio out RJ45 LAN port SFP adapter (CD662x only) Smart card reader (CD8624 and CD6624) DVI ports USB 2.
PAGE 3
CD8620-Series/CD6620-Series Thin Client Setup Safety and Precautions Prevent ESD (electrostatic discharge) damage to smart card readers by always discharging your body and smart card before using a reader (for example, by touching a grounded, unpainted, metal object). ESD can vary depending on many environmental conditions, including clothing that users wear and how they handle smart cards. ESD damage can potentially cause unsupported card reader behavior including failure.
PAGE 4
CD8620-Series/CD6620-Series Thin Client Setup, Continued Setting up a Thin Client (continued) Step Action 6 Connect the included power cord and AC adapter, and then plug the adapter into the rear of the thin client. Continue by plugging the power cord into an AC power outlet. 7 Power on the thin client by pressing the power button. NOTE: The thin client displays the BIOS splash screen and a Windows operating system animation, then the displays are blank.
PAGE 5
CD8620-Series/CD6620-Series Resources and Support Additional Information ClearCube Sentral Administrator’s Guide describes how to use ClearCube Sentral to manage thin clients, chassis, and related devices; perform connection brokering; and more. Contacting Support Web site: www.clearcube.com/support Email: support@clearcube.com Phone: (512) 652-3400 Toll-free: (866) 652-3400 G0200168, Rev B 2014.07.
