Instruction Manual

CD8620-Series/CD6620-Series
ClearCube Technology, Inc. www.clearcube.com [phone] 2 of 5
Overview, Continued
Features
The pictures below show CD8620- and CD6620-series thin client features. Some features
vary by model.
Thin Client
Overview
A Cloud Desktop, or thin client, is a remote computing device that connects a user’s
monitors, keyboard, mouse, speakers, and other peripherals to remote PC blades (computers)
and to virtual desktops (VMs). As shown below, computing resources are typically located in
remote data centers.
Thin clients enable users to work on a blade or VM as if it is a local PC using a remote
connection protocol. See the documentation for the remote protocol application that you use
for additional information.
HDD activity
Power button
Network activity
Audio in
Audio out
Smart card reader
(CD8624 and CD6624)
USB 2.0 ports
Speaker
Pedestal
USB 3.0 ports
PS/2 port
USB 2.0 ports
RJ45 LAN port
DVI ports
DC jack
COM port
SFP adapter
(CD662x only)
Network Infrastructure
Thin Client with
Monitors and Peripherals
Chassis with
Blades and VMs
Copper and Fiber Ethernet
(Network Media Varies by Model)
