USER MANUAL CRC 7200 STEREORADIO
Safety Informations Dear customer! First of all thank you very much, that you have decided for the cmx® CRC 7200! Please read all information’s carefully before you start running the cmx® CRC 7200. Our company reserves the right to improve the product. That changes to specifications and design, also without notice. If you have problems, please visit our website at www.cmx-electronics.com and select your device.
Safety Informations Index of contents 1. SAFETY INFORMATIONS .............................................................................. 4 2. LOCATION OF CONTROLS ............................................................................ 5 3. INCLUDED IN DELIVERY ............................................................................... 6 4. CONNECTORS .............................................................................................. 7 4.1. POWER SUPPLY ...............................
Safety Informations 1. Safety Informations CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash is a warning sign alerting you of „dangerous voltage“ inside the product. The exclamation point is a warning sign alerting you of important instructions accompanying the product. WARNING To reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. Refer servicing to qualified service personnel.
Location of controls 2. Location of controls 15 14 1 13 2 3 12 11 4 10 56 7 8 1. 2. 3. 4. 5. 6. 7. 8. 9. 9 CD door Display Speakers (left/right) CD “STOP“ CD “PAUSE” CD “PLAY“ CD “REPEAT“ CD “PROGRAM" CD “NEXT“ Version 1 cmx® CRC 7200 3 10. CD “BACK“ 11. Radio tuning control 12. Function switch (AM / FM / OFF) 13. Volume control 14. Radio dial scale window 15.
Included in delivery 3.
Connectors 4. Connectors 4.1. Power supply This set works on normal household AC-power. Make sure the set voltage of unit matches your local voltage. Insert the plug oft he AC-cord into a wall outlet with ACpower. NOTE Please make sure to set the function switch to “OFF“ position when unit is not in use to conserve power 4.2. Battery operation Open the battery door and insert 6 pieces “C-cell” (UM2/LR14 type) batteries. Please observe correct battery polarities or the set will not work.
CD-Player 5. CD-Player 5.1. Insert and removal of discs When opening the CD-door, always ensure the discs is not in motion (not spinning) when you open the CD-door. Always press the “STOP” key to stop the disc spinning first. Place a CD into the compartment with the label-side (printed side of disc) facing upwards. Press down in the center part of disc until the disc “locks” onto the center spindle. When the CD has been placed onto the center spindle, gently lower the CD-door downwards until it locks shut.
CD-Player At anytime during playback, press ”STOP” key to stop the operation of the set. This will reset the set to the first track. At anytime during playback, “press and release” the ”BACK/NEXT” keys to skip backwards or forwards by one track, as desired. 5.3. CD repeat At anytime during playback, press the “CD REPEAT” key once, than the set will repeat the current track (Repeat symbol will “flash”).
CD-Player After a maximum of 20 songs (or less) have been selected as described above, press the “P-PROG.” key. The display will now indicate the exact song sequence in memory by displaying all song numbers rapidly. Also, the “Program” symbol will remain “on” to indicate that you have saved a program-memory (sequence). Pressing “PLAY” key will now play back the “saved sequence” in the program memory. Pressing “NEXT/BACK” will move to the next or previous song in the saved sequence.
Radio 6. Radio Set the function switch to “radio”. Set the radio band selector switch to the desired band. FM radio reception: fully extend the FM antenna wire and adjust its position AM (MW) radio reception: rotate or re-position the main unit Rotate tuning knob to tune-in the desired station, as displayed in the LCD digital display. Adjust the volume to desired level.
Specifications 7. Specifications Formats Audio-CD / CD-R / CD-RW Connectors headphone Radio AM / FM Frequency AM FM Speakers maximum 80 Watt PMPO Power consumption 15 W Power supply AC 230 V ~ 50/60 Hz Batteries 6 pieces C/UM-2/LR14 – 9V 530 – 1600 kHz 87,5 – 108 Mhz The apparatus should not be exposed to dripping or splashing and no objects filled with liquids should be placed on the apparatus. The marking and rating label is located at rear enclosure of the apparatus.
Specifications Excessive sound pressure from earphones and headphones can cause hearing loss. Electrostatic discharge (ESD) Precaution When electrostatic discharge (ESD) occurs at the front surface (whether metal or plastic) or near any part or any buttons of this unit there may be a possibility that the product may stop operation and/or shut down immediately. This is a normal condition and intended to protect the unit and internal components against damage.
