General VER0320097380 STEREO RADIO CRC 7380 USER MANUAL -1-
General Imprint All rights reserved. Any reproduction without consent of cmx® is prohibited. cmx® reserves the right to modifications of the device.
General CONTEXTS 1. GENERAL ...................................................................................... - 1 1.1. Safety precautions .................................................................- 1 1.2. Disposal of Waste Electronic Equipment ..............................- 1 1.3. Battery Disposal ....................................................................- 2 1.4. Copyright ...............................................................................- 2 1.5. Hearing Protection .....
General 1. General 1.1. Safety precautions Only connect to mains power supply (230 Volt/50 Hz). Do not place the device in close proximity of water (e.g. sink, wash basin, etc.). The device can fall into the water and cause a short circuit. The device consumes some power during standby operation. For zero power consumption disconnect from mains power supply. Place the device on a stable surface to prevent it from tipping over and causing damages or injuries.
General Ask your municipality for collecting points for waste electronic equipment. Do not dispose of old appliances with the household waste. The symbol on the product, the instructions for use or the packing will advert about the methods for disposal. 1.3. Battery Disposal The law requires returning exhausted batteries to public collection points or to the dealer. Do not dispose of exhausted batteries with the household waste. 1.4.
General 1.6. Cleaning and Maintenance Before cleaning disconnect from mains power supply. Cleaning the Casing Clean the casing with a dry cloth. Cleaning CDs Clean CDs with a soft cloth from the center to the edge. Do not use pointed or sharp utensils for cleaning, this will damage the CD. Cleaning the Laser Dust or dirt can collect on the laser pick-up. Only use a commercially available special cleaner. Do not clean with liquid cleaning agents or a wet cloth, this can cause a short circuit.
Features 2. Features This stereo radio can play all Audio CDs and MP3 CDs. Music playback is also possible via USB port and SD card reader. You can operate the stereo radio with a power cable or batteries. Batteries not included in delivery.
Location of controls 3. Location of controls 3.1. Main unit 1 2 3 4 5 6 7 8 9 10 1 PHONES Earphones/headphones jack 2 REP./RAN. Select playback mode 3 PROG.
Location of controls 11 12 13 14 15 16 13 17 18 11 FUNCTION Function selector RADIO, OFF, MP3/CD 12 -VOLUME+ Decrease volume Increase volume 13 Speaker speaker (left & right) 14 SD JACK SD or MMC card slot 15 LCD Display 16 USB JACK Port for MP3 player / USB stick 17 Tuning Select radio function 18 AM/FM/FM ST. Switch to AM/FM/FM ST.
Preparation 4. Preparation 4.1. Connection with cable Follow this step to connect the system: 1. Connect the mains power cable first to the system and then to a wall outlet. 4.2. Operation with batteries 1. Open the battery door and insert 8 batteries (1,5V, UM2/C/LR14). Please observe correct battery polarities. When the set is not used or is only used with “AC”, please remove the batteries, to avoid damage to set from leakage of batteries. 5. CD-Player 5.1. Insert CD / MP3-CD 1.
CD-Player 2. Insert a CD with the label up and carefully press it down onto the ball bearing spindle. 3. Close the CD drive manually. 5.2. CD / MP3-CD playback 1. Set the function switch to MP3/CD. 2. Press PLAY/PAUSE/USB key and the disk will start spinning and than playing the first song (track). This system can play CDs / MP3 CDs in different playback modes. 1. Press REP./RAN. Settings Repeat Playback Repeat current track. (press once) Repeat All (press twice) Repeat all tracks on the CD.
Radio 5.3. Program CD/ MP3 tracks You can program your own playlist with up to 99 tracks. 1. During CD / MP3-CD playback press the STOP button before programming. 2. Press the PROG. button until P01 is displayed. 3. Press NEXT( ) or BACK( ) until the desired track is displayed. 4. Press the PROG. button to confirm. 5. Repeat step 3 and 4 to program further tracks. 6. Press the PLAY/PAUSE/USB button to start playback. 6. Radio 6.1. Listen to radio 1. Set the function switch to RADIO. 2.
External components 7. External components 7.1. Connect earphones 1. Connect you earphones or headphones. The speakers are muted if earphones are connected. To avoid hearing problems do not use earphones or headphones for an extended period of time. Increased sound pressure from earphones or headphones can cause hearing loss. 7.2. USB 2.0 Extend your system by connection your MP3 player or USB stick. Do not disconnect the device when „USB“ mode is selected. 1. Connect your MP3 player or USB stick.
Troubleshooting 7.3. SD and MMC card reader Extend your system by inserting a SD or MMC memory card in the card reader. Do not disconnect the device when „SD“ mode is selected. 1. Insert the SD or MMC card in the card reader. 2. Set the function switch to MP3/CD. 3. Press the STOP/SD button until “SD” is displayed. 4. Press the PLAY button to start playback. To avoid damage only disconnect the device after pressing the STOP button and selecting a different mode with the function selector. 8.
Warranty Try another CD or clean the CD. Bad reception Increase the distance to TV set or DVD player. Point the antenna in a different direction. System does not Disconnect from mains power supply respond. No sound and reconnect after a few seconds. Increase the volume. Disconnect the earphones. No CD playback Check your CD for damages or scratches. Insert the CD with the label up. USB stick / SD memory card does Use a different USB stick or SD card to check the function.
Warranty In case of manufacturing or material defects the warranty consists of rectification of defects or exchange. The warranty does not include damages or troubles in case of malfunctions due to improper use wear and tear repairs by third parties The warranty does not include display damage accidental damage Repair does not extend the warranty period. 9.1.
Warranty 9.2. Warranty has expired Please contact us by phone or contact form in case your warranty has expired. We will help you! Please inform us about the following: Unit type Purchase date Malfunction 9.3.
In the box Unit malfunctions Unit cannot be switched on Sender information: Name, address, ZIP code, city and phone number and e-mail address 10. In the box Please contact your dealer directly in case one of the accessories is missing or damaged.
Technical specifications 11. Technical specifications CD-Player Formats Audio CD / Audio CD-R / Audio CDRW MP3-CD / MP3-CD-R / MP3-CDRW Radio Frequency bands AM / FM / FM Stereo frequencies AM FM 520 – 1620 kHz 87,5 – 108 MHz Connectors Input USB 2.0 – 1.1 compatibel Outputs 3,5 mm headphones Card reader SD cards MMC cards Speakers Power output Max.
Technical specifications www.cmx-electronics.
