User's Manual

Unplug the CC Debugger from Inn-Car Trigger when flash programmer
generate programming successfully message.
13.2 Serial Bootloader
Serial Bootloader provide a pure software process to flush the firmware of
controller with provided firmware image file. The process requires no specific
fixture or removing the cover case.
13.2.1 Environment setup
The M12 pigtail of In-Car Trigger have to be connected to a 8~30V power
supply and Windows system host device. Make sure In-Car Trigger is powered
on, the connected Windows system successfully identify the UART interface on
M12 pigtail, and DO NOT let any application (includes the In-Car Trigger Test
UI) on Windows system occupy the UART port.
13.2.2 Firmware flushing
The listed file will be provided for the usage of serial bootloader function.

InCarTriggerBootloader.exe: An executable of serial bootloader
application.

InCarTriggerBootloader.bat: Batch script.
 InCarTriggerFW_A****.bin: In-Car Trigger controller firmware.
[Note]
Serial Bootloader is staring phasing-in In-Car Trigger controller firmware since V1.01
to provide ability to update the controller to the LATER version firmware. If the
current controller firmware version of In-Car Trigger is less than V1.01, it still require
to hardware flushing the firmware to V1.01 with provided firmware image first to
support serial bootloader.
